Specification:
Brand name: SKYSTARS
Item name: G520S FPV Racing Drone PNP
Weight: 366.33 (without propeller)
| Frame Kit |
Frame Kit
Name: Skystars G520S-AIO-2019
Wheelbase: 228mm
Props Size: 7inch
Arm Plate Thickness: 4mm
TOP Plate Thickness: 1.5mm
Material: 3k Carbon Fiber and Aluminium alloy
Screw: TAIWAN YFS BRAND SCREW 12.9 level screw
Weight: 130g
|
| Flight Controller |
FC Specifications:
MCU: 168MHz STM32F405
IMU: MPU6000 accelerometer/gyro (SPI)
Baro: BMP280 (I2C)
OSD: BetaFlight OSD w/ AT7456E chip
Blackbox: MicroSD card slot (SD/SDHC)
VCP, UART1, UART2, UART3, UART4, UART5
Built in inverter for SBUS input (UART2-RX)
PPM/UART Shared: UART2-RX
SoftSerial on TX2, S5 or S6 optional
Camera control on S6 or DAC optional
Smartaudio & Tramp VTX protocol supported
WS2812 Led Strip : Yes
Beeper : Yes
RSSI: Yes
PDB Specifications:
Input: 6~30V (3~6S LiPo) w/TVS protection
PDB: 4x50A , 4 layers*2oz copper PCB
BEC: 5V 3A cont.
LDO 3.3V: for Spektrum RX
Current Sensor 184A (Scale 179)
Battery Voltage Sensor: 1:10 (Scale 110)
|
| Brushless ESC |
Features:
- Support Dshot 1200 in default out from factory
- Also support Oneshot42, Oneshot125, Multishot, Dshot150, Dshot300 and Dshot600
- Ultra light and ultra small ESC - The color of RGB LED can be set by Blhelisuite. -Powered by high performance STM32 MCU frequency up t0 48 MHZ -Composed of 3Oz gold plated PCB -Flashed with the latest BLheli32 firmware -Supports higher KV motor and more power load, more suitable for violent flight of racing drone. -Aluminum heat sink effectively slow down the temperature rise.
35A 2 - 5S Blheli-32 RGB light ESC:
Input Voltage: 2 - 5S Lipo battery
Constant Current: 35A
Peak Current: 50A
BEC Output: no
CPU: STM32F051 BLHELI-32 firmware
MOS Tube: TOP QUALITY MOSFET
|
| Brushless Motor |
skystars 2306 V2 KV 2750, race edition,hollow shaft
Made of NMB bearings and curved magnets for longevity and efficiency
|
| VTX |
FPV Transmitter
Output power: 25mW/200mW/600mW switchable
Control mode:button OR Channel changes and Pitmode setting through PWM TBS SmartAudio inside
BAT: 7-26V,BEC 5V-1A
270mA----600mW
Video system: NTSC/PAL
Antenna: MMCX
Frequency: 5.8GHz 5 bands 40channels
Weight: 4.2 g
Dimension: 36*36*4.85mm
Mounting Hole: 30.5mmx30.5mm
|
| Camera |
Model RunCam Swift 2
Image Sensor 1/3" SONY Super HAD II CCD
Horizontal Resolution 600TVL,4:3
Lens 2.1mm 165°
Signal System PAL
Integrated OSD YES
Integrated MIC YES
S/N Ration >60dB(AGC OFF)
Electronic Shutter Speed PAL:1/50~100,000; NTSC:1/60~100,000
AutoGain Control(AGC) YES
Back light compensation(BLC) YES
Min.illumination 0.01Lux/1.2F
WDR D-WDR
DNR 2DNR
Day/Night Color / Auto / B&W
Power DC 5 to 36V
Net weight 14g
Dimensions 28.5mm * 26mm * 26mm
|
| Propeller | DALPROP 5040 3-blade |
| GPS |
Mini M8N GPS Module UBX-M8030 For Mini PIX / F4 / F7 Flight Controller
Description:
Brand name: SKYSTARS
Item name: ST100 Mini M8N GPS
Size: 31*30*12mm
Weight: 22g
Positional accuracy: 50 centimeter precision when working with concurrent GNSS
Velocity precision: 0.1m/s
Max height: 50000m
Max speed: 515m/s
Max acceleration: 4G
Max update rate: up to 10Hz
|
| Antenna |
RHCP 5.8G 2.5dBi Super Mini Antenna For FPV Racing Drone Weight: 7.4g
Size: 60mm x 17mm
Gain: 2.5dbi
Axial ratio: <1.0 (near perfect)
Bandwidth: 5.5GHz-6.0GHz
Radiation Efficiency: 98%
VSWR: <=1.2
Connector: SMA
Works great as both a transmitting or receiving antenna
Compatible with other styles of 5.8GHz RHCP antennas
|
Package Included:
1 x Skystars G520S-AIO-2019 Frame Kit
1 x F4 8K OSD Flight Controller
4 x 35A 2-5S Blheli-32 RGB light ESC
1 x 5.8G 40CH 25mW/200mW/600mW switchable VTX
4 x skystars 2306 V2 2750KV Brushless Motor
1 x RunCam Swift 2 Camera
8 x DALPROP 5040 3-blade propeller (2 Pairs CW, 2 Pairs CCW)
1 x Buzzer with battery
3 x Battery Strap
2 x Battery Anti-slip plate
1 x Antenna
1 x XM+ Receiver (Optional, Only XM+ Receiver and PNP+GPS+XM+ Version are included)
1 x GPS (Optional, Only GPS Version with this module)
