Description:
Brand name: Skyzone
Item name: RX5803 FPV Receiver Module
Channel: 48CH Raceband
Volume: 35x24x3.5mm
Weight: 4.2g
The recommended working conditions (if not up to the recommended working conditions may not meet the specified electrical performance criteria) Parameter Symbol Working conditions Minimum value Typical value Maximum value Unit Supply voltage VCC 3.5 5 5.5 V Power ripple voltage VIp 10 25 mVPP Input voltage Vi GND VCC V Working temperature Ta Only the module itself -20 27 70 â Electrical characteristics(VCC=5.0V,Ta=25 â) Parameter Symbol Working conditions Minimum value Typical value Maximum value Unit Supply current Icc Vcc=5.0V - 170 180 mA Radio Frequency Receiving sensitivity RFin 50Ω system - -95 dBm Receiving frequency 5362 5945 MHz Frequency stability Fstb -100 +100 ppm Input impedance RFin 50Ω system 50 Ω Input VSWR VSWR 50Ω system 2:1 Video Video output impedance Rvo 75Ω Ω Video output level Vvo Negative polarity
75 load 0.9 1 1.25 Vpp Frequency response Fbdv 50Hz - 6MHz -5 +5 dB Signal-to-
noise ratio S/N 38 dB Audio Subcarrier demodulation frequency Far 6.5 MHz Audio output impedance Rao 1KHz sine wave 600 1K Ω Audio output level Vao 1kHz sine wave
dual channel 0.8 Vpp Frequency response Fbda 100-10KHz
1.0VPP sine wave 100 10K Hz Harmonic distortion THD 1KHz,1.0Vpp sine wave 0.6 1.5 % Received signal strength indicator VRSSI RFin:95dB-5dB 0.5 1.1 V Signal-to-
noise ratio S/N 1KHz,1.0Vpp sine wave 45 dB
CH
FR CH (MHz) CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
FR FR1(A) 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M FR2(B) 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M FR3(E) 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M FR4(F) 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M FR5(R) 5658M 5695M 5732M 5769M 5806M 5843M 5880M 5917M FR6(L) 5362M 5399M 5436M 5473M 5510M 5547M 5584M 5621M
Feature:
1.5.8GHz 48CH Raceband
2.FM Simultaneous reception of audio and video
3.Low power consumption, high receiver sensitivity
4.Built in frequency PLL with high stability
5.Low clutter leakage: meets CE, FCC requirements
6.Direct output analog audio, video signals
Package included:
1 x Skyzone RX5803 Receiver Module
