Description:
Brand: SPT
Product: SPT70HV-320 70KG 320°Digital Servo
Dead Band: 4μs
Neutral Position:1500μs/330Hz
Motor: Core Motor
Remote Control Angle: 160°
500-2500us Angle:320°/PWM
Voltage Range: 4.8V-8.4V(BEC≥3A)
Operating Speed(6.0V): 0.20''/60°
Operating Speed(7.4V): 0.16''/60°
Stall Torque(6.0V): 56 kg.cm
Stall Torque(7.4V): 70 kg.cm
Dimensions: 65.7*30*57mm
Weight: About 200g
Connector Wire Length: JR 260 mm
Bearing: 2BB
Application: For RC Car, RC Robot Arm
Package:
1* SPT SPT70HV-320 70KG 320°Digital Servo
