Eachine Tyro99 210mm DIY Version FPV Racing RC Drone w/ F4 OSD 30A BLHeli_S 700TVL Camera
Note:
1. This is the DIY version that comes unassembled.
2. Make sure the antenna is installed at the output end before powering up to avoid damaging internal components;
3. Note that the input voltage is within the specified range and is correct and correct to avoid damaging internal components;
4. If the antenna is replaced, select a standing wave and a gain antenna for a longer transmission distance;
5. Pay attention to classic protection during transportation and installation.
6. Take-off weight is about 450g.
| Item | Specification |
| 210mm Frame Kit |
Wheel base: 210mm
Frame arm thickness: 5mm
Bottom plate thickness: 2mm
Side plate thickness: 2mm
Frame kit material: 3K carbon fiber & 6065 aluminium
|
| 2206 2150KV Brushless Motor |
Motor KV: 2150RPM/V
Idle current (Io/10V): 1.26A
Lipo cell: 3-5S
Weight: 31g
Max continuous current: 31A
Max continuous power: 496W
Max thrust: 1050g (4S/5")
Configu-ration: 12N/14P
Motor resistance (RM): 0.0572 Ω
Stator diameter: 22mm
Stator thickness: 6mm
Motor diameter: 27.7mm
Motor body length: 19.2mm
Overall shaft length: 34.2mm
Prop adapter shaft: M5
Bolt holes spacing: 16mm
Bolt thread: M3
Propeller: 5-6 inch
|
| 4 IN 1 30A BLHeli_S ESC |
Continuous current: 30A
Peak Current: 40A(10S)
Input voltage: 2-5S
BEC: 5V 2A BEC
Main control chip: 48Mhz EFM8BB2
Firmware: BLHeli_S supports Dshot600
MOS: 5*6 |
| Customized F4 Flight Controller |
Main control chip: STM32F405
Sensor: ICM20602 6-axis
Power supply: 5V
Integrated OSD
Onboard LC filter
PID cycle rate & gyroscope refresh rate up to 32Khz
Supports BetaFlight / inav racing firmware
|
| 700TVL CMOS Camera |
Case size: 25mm*25mm
Weight: 9.5g
Total pixels: PAL: 1020H×596V (0.61MP); NTSC: 1020H×508V (0.52MP)
Effective pixels: PAL: 976H×582V (0.57MP); NTSC: 976H×494V (0.48MP)
Signal system: PAL/NTSC switchable
Resolution ratio(horizontal center): 700TVL
Video output: 1.0Vp-p/75Ω
Automatic gain control: 0.25/0.50/0.75/1.00, up to 55dB
White balance: on/off optional
Exposure mode: electron exposure
Electronic shutter: 1/50(1/60) - 1/100000 S
Gamma correction: 0.45/1.0
Synchronization method: inter-sync
Camera lens: standard 2.8mm
Lens operating voltage: DC12V (wide voltage, measured can work normally at 7.5-13V)
Working current: 70mA (low power consumption)
Working temperature: -20â~-60â
Humidity: 0%~98%
|
| 5.8G 40CH 0mW/25mw/200mw/600mw switchable VTX |
Output power & transmission distance: ≥0.5km@25mW, ≥1km@200mW, ≥2km@600mW
Transmitting power: 0mW/25mW/200mW/600mW
Full video format: NTSC /PAL
Input voltage & power dissipation: 7V~24V, +12V/260mA@600mW
Size: 20*30*9mm
Weight: ≤7g(except antenna)
With output power self-check function.
Nixie tube SCAN: frequency point (1-8), frequency band (A-E),
power (1-3, 0=0mw, 1=25mw, 2=200mw, 3=600mw) |
| Racerstar 5038 2 Blade Propeller |
Material: PC
Mounting hole: 5mm
Center thickness: 8mm
Quantity: 10 pairs
Color: blue, red, yellow, purple, white
Weight: 7.25G a pair
Delivery color randomly (10 pairs of propellers are the same color)
|
| Battery |
Not included Recommend 3-5S |
Package Included:
1 x 210mm frame kit
2 x 2206 2150KV brushless motor CW
2 x 2206 2150KV brushless motor CCW
1 x 4 IN 1 30A BLHeli_S ESC
1 x Customized F4 flight controller
1 x 700TVL CMOS camera
2 x 2206 2150KV brushless motor CW
2 x 2206 2150KV brushless motor CCW
1 x 4 IN 1 30A BLHeli_S ESC
1 x Customized F4 flight controller
1 x 700TVL CMOS camera
1 x 5.8G 40CH 0mw/25mw/200mw/600mw switchable VTX
2 x Battery strap
10 x Racerstar 5038 2 blade propeller CW
10 x Racerstar 5038 2 blade propeller CCW
2 x Battery strap
10 x Racerstar 5038 2 blade propeller CW
10 x Racerstar 5038 2 blade propeller CCW
