Sunrise Model 60A 2-6S Brushless ESC for RC Models - 36.99 €

Sunrise Model Blade 60A 2-6S Brushless ESC with 8V 20A BEC for RC Models

Product features:
1. 32-bit ARM processor. Small size, light weight and rapid running speed.
2. High resolution, smooth and responsive throttle linear. Throttle signal loss protect implemented.
3. Synchronous rectification, regenerative braking, energy recuperation (saving >15% power compared with the other regular ESCs).
4. Automatically detect regular input signal. Throttle travel is available for setting to compatible with different TX.
5. Start up power is automatic with great acceleration.
6. Adaptive timing, compatible with much more motors.
7. Block protection. It will stop starting up motor when motor is blocked or can’t be started for a long time to protect motor from damage.
8. A programming card is designed for easy setting. Have complete independent intellectual property rights, firmware is sustainable for updates.

Parameter Spec:
1. Support 2-14S (Please check ESC sticker to verify the specified cells)
2. PWM output frequency range is 8-18KHz. Different PWM can be set by programming card.
3. Regular signal throttle range is 900us-2400us.
4. Max. RPM: 300,000rolls (2 poles), 100,000rolls (6 poles), 50,000rolls (12 poles)
5. Under voltage protection. HV ESC is anti-sparked (HV only).
6. Special designed governor mode and soft start up mode for Helicopters.
7. Big current will activate freewheeling to reduce heating greatly.
8. Adaptive timing. Or manually set timing, 6 options available.
9. Adjustable brake by proportion, 3 options available.
10.A programming card is used for implementing different settings.

Description:
Item Name:Sunrise Model Blade 60A 2-6S Brushless ESC
Con.Current:60A
Peak Current(10s):80A
BEC:YES
Lipo:2-6s
Programming:YES
BEC Output:5-8V/10-20A
PWM:8-18KHz
Weight:65g
Size(PCB):55*30mm
Instructions:


Package Includes:
1 x Sunrise Model Blade 60A 2-6S Brushless ESC
