Tarot 5.8G 32CH 7 Inch 800*480 FPV Monitor Diversity Receiver Displayer TL2967
Tarot production of 5.8G 32CH dual receive 7-inch high-definition FPV aerial display, the industry is very high integration of one of the monitors, and has a very small form factor, ultra-thin body, highly integrated internal procedures, the PVC RFA and RFB signal strength, RFA and RFB frequency, signal source, lock state, charge status (power) and other information, all designed to make people impeccable, the screen can directly display the receiver RFA and RFB signal strength.
Description:
Brand Name : Tarot
Item Name : 5.8G 32CH Monitor
Item NO.: TL2967
Power Specification :
Power Supply : DC11-26V
Power consumption: <8W
Signal Format: N system P automatic identification system
Battery Specifications: 18650 3.7 × 2 (not included)
Support Charging: support DC11-26V straight
Operating Temp. : -10 to 60â
Storage Environment: -30-60â
Wireless Frequency :
Frequency : 5.8G 32 channels
Receiving Channel : 5645-5945MHZ
Receive Sensitivity : -85 dbm
Modulation type : FM / PLL
Antenna Interface: SMA 50Ω
Display :
Menu Language : Chinese, English
Viewing Angle : 120 degrees / 70 degrees (horizontal / vertical)
Screen Type : TFT LCD Screen / long life, LED backlinht
Resolution : 800 × 480
Brightness : 400cd / m2
Aspect ratio : 16: 9 (can be set to 4: 3)
Parameter :
Package Size : 236 × 168 × 102mm
Monitor Size : 181 × 129 × 39mm
Net Weight: 510g
Features:
Can automatically search frequency, select the strongest signal frequency point of use;
Can be used as an ordinary display, just through the av in interface to the video signal, switch to av in mode can be used;
Can receive dual-frequency signals at the same time, all the way through the receiving screen display, the other way through the corresponding av out interface output to other monitors;
Can be placed in the product within the lithium polymer battery directly to balance the charge, easy to use;
Has a stopwatch timer function;
Screen lock function, can be set up to avoid unnecessary misuse;
Can be screen flip for different requirements of the location of the installation requirements.
Package Included :
1 x 5.8G 32CH 7 Inch Monitor
1 x Power adapter × 1 (input: AC 100-240V, output: DC 12V × 2A)
2 x Standard 5.8G receiving antenna × 2
1 x Video Input Cable
1 x Video Output Cable
1 x DC IN Cable
1 x User Manual
