This charging module is compatible with the Frsky x9 lite x9 lite Pro 18650 battery pack with built-in undervoltage lockout, overvoltage protection and overtemperature protection. It can be fixedly installed on the x9 lite x9 lite Pro remote control main board. The charging part of the charging module and the remote control can share the negative pole. The wiring is simple and reliable. After the module is installed, a 5V conventional USB charging cable can be connected to the remote control. The micro USB port is used to charge the battery in the remote control battery compartment. You no longer need to remove the battery, it will fully charge your battery after about 2-5 hours. This charging module is suitable for internal charging modification of the Frsky series and other brands using a 7.4V lithium battery powered remote control.
Description:
Brand Name: URUAV
Brand Name: URUAV
Item Name: TM-Charger Board
Input voltage: 5V
Input current: 0.5-2.1A
Input capacity: 10W
Charger current: about 1.2A
Size: 40*35mm
Weight: 3g
Charging mode: balance charge (Extend battery life)
Suitable for FrSky X9 Lite X9 Lite Pro 18500/18650 battery
Charging method: adaptive multi-segment charging (protecting the battery)
Colorful LED is always on: charging
Colorful LED is off: the charging is completed. After the charging is completed, the buzzer will stop after 60 seconds.
Package included:
1 x TM-Charger Board
