Walkera Rodeo 110 110mm FPV Racing Drone w/ 600TVL HD Camera 5.8GHz 40CH Transmission BNF RTF
to dowmload the manual
Specification:
Specification Walkera Rodeo 110 Size:101x117x55mm
Weight:101g(not include the battery) Remote Control DEVO 7
2.4GHz DSSS Frequency Hopping
≤100mW Output Power
≤230mA(100mW) Current Consumption
use 5# battery 8x1.5V or NiMH 8x1.2V 1600-2000mAh
1000-2000mS (the neutral point is 1500) Output pulse Receiver Rodeo 110 Flight Control Rodeo 110 F3 Transmission 40 Channaels
TX5834(FCC)/TX5835(CE)(Including OSD)
25mW(CE)~100mW(FCC)~600mW (Can be Upgradeable) Transmission power
500M (600mW)Transmission Distance Camera PAL/NTSC
600TVL HD Sony Resolution
1.0Vp-p/75 Video Output
DC 12V Power Input Brushless Motor WK-WS-13-002A Brushless ESC Rodeo 110 Lipo Battery 7.4V 850mAh 25C 2S Li-Po Flying Time 6 ~ 7 minutes Working temperature -10â~+40â
Features:
1.Combined with a strong brushless motor power and high-strength carbon fiber frame kit
2.Front-view lighting, HD camera and 5.8GHz real-time transmission, allowing you to be barrier-free flight in the dark indoor
3.With the size and weight of the hollow-cup aircraft, the violent acceleration of the racing drones allows you to indulge in the fun of flying indoors
4.Rodeo110 uses integrated PCB circuit board, inherit PDB, flight control, transmission, receiver and other modules in one, the size is only 33mmx68mm,
significant savings in space and weight, in order to obtain a smaller size and greater Thrust - weight ratio.
5.Core components closed modular design, power transfer, map-chip are plug-in installation, easy installation and disassembly, easy to post-maintenance, maintenance
Package included:
BNF Version:
1 x Walkera Rodeo 110 frame kit
1 x Receiver
1 x 600 TVL Camera
1 x Transmission
4 x Brushless Motor
4 x Brushless ESC
1 x Battery
1 x Charger
RTF Version:
1 x DEVO 7 Remote Control
1 x Walkera Rodeo 110 frame kit
1 x Receiver
1 x 600 TVL Camera
1 x Transmission
4 x Brushless Motor
4 x Brushless ESC
1 x Battery
1 x Charger
