XDRC ZHI 230mm Wheelbase 5mm Arm Thickness 3K Carbon Fiber Frame Kit for RC Drone FPV Racing
Specification:
Model: ZHI 230
Item Name: 230mm Wheelbase Racing Frame Kit
Wheelbase: 230mm
Material: 3K Carbon Fiber
Arm Plate Thickness: 5mm
Arm Plate Width: 10mm
Frame Body Length: 155mm ( include camera mount)
Frame Height: 39mm
Frame Width: 48mm ( Max.)
Top Plate Thickness: 2mm
Bottom Plate Thickness: 2mm
Weight: 121g
Recommend Parts: ( NOT Included)
FC & ESC Stack: DALRC F722 F7 Flight Controller & Rocket 50A 3-6S BL_32 ESC
T-Motor F55A PRO II 55A 4-6S BL_32 ESC & F4 HD Flight Controller
Brushless Motor: RCINPOWER GTS2306 2306 V2 2500KV 3-5S FPV Racing Motor
FLYWOO NIN PLUS N2306.5 2306.5 2450KV 3-5S Brushless Motor
Propeller: 2 Pairs Gemfan Hurricane 51499 3-blade 5mm/POPO Propeller CW CCW
Gemfan Hulkie 5055S 5055 5 Inch 3-Blade Propeller 2 CW & 2 CCW Support POPO
FPV Camera: Caddx Turtle V2 1080p 60fps FOV 155 Degree Super WDR FPV Camera
Lipo Battery: 4S 1300mAh-1550mAh 95C-120C Lipo Battery
Package Included:
1x ZHI 230mm Racing Frame Kit
2x Battery Strap
