Upgrade specification:
New way to charge 1S JST-PH 2.0 Lipo Battery.
Max support charging 5 same 1S Lipo Batteries
Most versatile parallel board for 1S/2S/3S
Features:
Support 6 packs XT30 / 1S / 2S or 3S LiPo batteries balance charge.
Thicken PCB copper foil, allow security using 20A charging current.
Balanced port output line with 18AWG multi-strand silicone line.
Equipped with 20A fuse protection between any two groups of batteries, to handle the large battery pressure.
This ParaBoard can be used for batteries with JST-XH type balance plug (the most popular type in the market) and XT30 connectors.
Specifications:
Item name: Parallel Charging Board
Balance output cable: 18AWG silicon cable
Current: Support MAX. 20A charge current
Para board size: About 80 * 50mm
Compatible for IMAX B6 charger
Package included:
1 X T30 1S-3S Plug Parallel Charging Board
1 X JST-PH 2.0 Connecting Cable
6 X T30 Male to JST Female Cable
