Description:
EFFIO is a digital signal processor (DSP) developed by Sony for video surveillance cameras. It can provide high resolution image quality, high signal-to-noise ratio (SNR), and high color reproduction capability for video.
Effio DSP supports NTSC-standard 480K effective pixel CCD, and PAL specification 570K effective pixel CCD. With the Effio DSP and the new CCD, the resolution of more than 650 TVL levels can be achieved. Compared with the standard camera, this method can provide a clearer image. Its color signal processor provides ideal color brightness and concentration balance.
The Effio DSP supports Wide Dynamic Range (WDR) CCDs, which can also display clear images in environments where backlight and brightness contrast are extremely high. Effio DSP can improve the performance of "Super HAD CCD II". Sony's image sensors have a high degree of stability and sensitivity and are widely deployed in surveillance cameras.
Effio DSP combines 2D and 3D noise reduction functions to achieve dynamic resolution even when shooting moving objects. In addition, the Effio DSP incorporates peripheral circuitry that not only reduces camera size but also reduces power consumption.
The Effio DSP supports Wide Dynamic Range (WDR) CCDs, which can also display clear images in environments where backlight and brightness contrast are extremely high. Effio DSP can improve the performance of "Super HAD CCD II". Sony's image sensors have a high degree of stability and sensitivity and are widely deployed in surveillance cameras.
Effio DSP combines 2D and 3D noise reduction functions to achieve dynamic resolution even when shooting moving objects. In addition, the Effio DSP incorporates peripheral circuitry that not only reduces camera size but also reduces power consumption.
Specifications:
Item Name: EFFIO-E 4140+639 CCD Main Board Chip
CCD Type: 1/3" SONY SUPER HAD CCD
Size: 32mm*38mm
Signal system: PAL
Pixel: 752H×582V
Horizontal Clarity: 650TVL
Digital Noise Reduction: 2D digital noise reduction (2DNR), supports 16 levels adjustable from 0 to 15
OSD Menu: Support
Minimum Illumination: 0.005LUX/F1.2
Signal to Noise Ratio: ≥48dB
Video Output Amplitude: 1.0Vp-p/75Ω
Automatic Gain Control: 0.25/0.50/0.75/1.00 four levels can be adjusted, can reach the highest 55dB
White Balance Mode: On/Off selection
Backlight Compensation Mode: High Brightness Backlight Compensation (HLC) / Backlight Compensation
Exposure Mode: Electronic exposure
Electronic Shutter: 1/50 (1/60) - 1/100000 seconds
Gamma Correction: 0.45/1.0
Synchronization Mode: Internal synchronization
Audio: None
Operating Voltage: DC12V±5%
Working Temperature: -20°C--60°C
Humidity: 0% to 96%
Features:
Features:
Single board, low illumination.
Color to Black (D/N), IR Sensitive.
Support OSD menu function and eight languages.
With lightning protection,safe to use.
Package Included:
1x Motherboard
Color to Black (D/N), IR Sensitive.
Support OSD menu function and eight languages.
With lightning protection,safe to use.
Package Included:
1x Motherboard
