Specification:
Brand name | RCINPOWER | |
Item name | EX2306 | |
KV | 2550KV | 2750KV |
Configu-ration | 12N14P | 12N14P |
Stator Diameter | 23mm | 23mm |
Stator Length | 6mm | 6mm |
Shaft Diameter | 3mm | 3mm |
Motor Dimension(Dia. Len) | Ф28.69*32.25mm | Ф28.69*32.25mm |
Idle current(10)@10V(A) | 1.45 | 1.65 |
No.of cells | 3-5S | 3-4S |
Max Continuous power(W)180S | 830 | 740 |
Internal Resistance | 45mΩ | 38mΩ |
Max Current(30S) | 425 | 50A |
Max. Effciency Current | (3-6A)>83% | (3-6A)>81% |
Weight | 33 (3cm Wire) | 33 (3cm Wire) |
Package Included:
2 x EX2306 Brushless Motor
