Note:
Screw diameter: M2
Screw hole depth: 2mm
Fixing screw length: flight control thickness (including the thickness of damping ring) + 2mm
When the screw does not have the right length, please use spacers to fill the gap so that the flight controller cannot move freely.
Maximum torque of screw locking 0.2mm
Description:
Brand: MAMBA
Item Name: MAMBA RACE Brushless ESC
INPUT VOLTAGE: 3~6S Lipo (12.6V~25.2V)
CONTINUE CURRENT: 75AÃ4
BURST CURRENT: 85A (10S)
BEC: NO
SOFT: Dshot300/600/1200
Target: BLHeli_32 MAMBA RACEF75_BL32
TVS Protection: Yes
Mounting: 20mm/M3/M2
CURR: Yes
Telemetery: Yes
Output Current: 60A
Size: 40.5x32x10.5mm
Weight: 17g
Package Included:
1x MAMBA RACE F75_BLS32 Brushless ESC
2x 8pin sh1.0
1x AMASS Original XT60
1x High-Frequency 470uF/35V
