4 PCS 805 Micro 0.36 Inch Digital Voltmeter DC 0V-100V Three Wires 3 Digit Voltage Panel Meter LED Display for RC Airplane Car Boat Motorcycle
The voltmeter is small, only 0.36 inches, range DC DC0-100V, 2 and 3-wire generic products, to break the routine voltmeter, is the latest design, can work directly on 5V, 9V, 12V, 24V and other circuits, without regulation. With three wiring, easy access to car / battery car / motorcycle car line, with reverse polarity protection function, line reversed not burn. Used to monitor battery voltage, grasp the battery voltage state, it can also be used for other products voltage measurement applications.
Feature:
Stability, high measurement accuracy
Overall standard size, easy installation
Power supply protection circuit using a polar
NOTE: Three-line voltage range 0-100V, but also for the use of second-line voltage is within 30V, otherwise there is a danger of burning.
Technical Parameters:
Operating voltage: 4.0 ~ 30V (with a reverse polarity protection function)
Detection voltage: 0.0 ~ 100V
Operating Current: <20mA
Display: 0.28 "LED, red green blue yellow (colors)
Dimensions: 30 × 11.7 × 9.2 mm (length*width*height)
Installation hole: 32.6 × 14mm
Measurement rate: ≥200mS / times
Accuracy: 3 ‰
Extreme working conditions
Low operating voltage: + 4.0V
Maximum working voltage: + 30V
Working temperature: -10 ~ + 65°C
Humidity: 10 to 80% (non-condensing)
Working pressure: 80 ~ 106kPa
Sun exposure: no direct exposure
Package Included
4 x 805 Micro 0.36 Inch Digital Voltmeter DC 0V-100V Three Wires 3 Digit Voltage Panel Meter LED Display for RC Airplane Car Boat Motorcycle
