Specification:
Brand Name: iFlight
Model: XING-E 2306
Item Name: 2306 2450KV 2-4S Brushless Motor
KV: 2450KV
Input Voltage: 2-4S Lipo
Version: CW Screw Thread
Quantity: 4 PC
Configuration: 12N14P
Stator Diameter: 23mm
Stator Length: 6mm
Shaft Diameter: 5mm
Motor Dimension: 29.5x18.7mm (Dia*Len)
Weight: 33.1g
Idle Current(10) @10V: less than 2A
Max. Con. Power (180S): 748.8W
Internal Resistance: 47.3mΩ
Max. Current (180S): 344.57A
Package Included:
1x iFlight XING-E 2306 Motor
1x Motor Nut
4x Screws
