Description:
Brand name: AKK
Item name: XT60 Paralell charging board
Compatible battery types: 3S/4S Lipo
Brand name: AKK
Item name: XT60 Paralell charging board
Compatible battery types: 3S/4S Lipo
Maximum charging current: 20A
Fuse: 30A fuse×3 (replaceable)
No-load current: 17mA-22mA
Input connector: banana plug
Output connector: XT60
Board size: 8*5cm
Weight: 65g
Cable length: banana plug cable: 17cm
5 pin cable: 15cm
Features:
* Supports up to 4 same battery packs charging simultaneously (3S or 4S lipo).
* LED Display to show total voltage and the voltage of each battery cyclically.
* High-quality AMASS XT60 connectors; replaceable 30A fuse between any two ports; thicken PCB copper foil provide a 20A safe charging current.
* Compatible with most balance charger that with banana port.
Voltage display instructions:
It will display a total voltage firstly;then display average voltage of single cell in a 3 seconds cycle ("OC1"=the 1st cell; "OC2"= the 2nd cell...)
Note:
1. Only supports charging the same type of battery at the same time(3S/4S Lipo)
2. Please keep it in a safe place to prevent short circuits
Package Includes:
1x AKK XT60 Parallel Charging Board
