ALZRC Devil 380 FAST RC Helicoper Standard Combo
Description:
âWith FBL pros and cons linkage rod,Plastic dual-bearing swashplate.
âOver 90% of screw using Taiwan YFS 12.9 Class socket button head screw,equipped with red aluminum screw washer.
âEquipped with all-metal improved five connection points motor mount.
âEquipped with plastic swashplate servo mount,accurate fixed position,apply to most commercially micro swashplate servo.
âImproved and thickened carbon ficer tail boom.
âWith plastic tail rotor control arm assembly.
âBig battery compartment and slideway design, more convenient for install and disassemble.
âWide selection of batteries with different capacities 6S 1500~2600 mAh.
âImproved with simple and elegant canopy Combo.
âThe key parts of the screw with a gasket,and the decorative gasket be canceled.
âPlastic locked rudder servo mount, apply to Medium-sized servo.
âWith magnetic quick release canopy mounting bolt.
âAdapting Medium performance Tail Drive Gear Belt.
Specification:
âMain rotor diameter: 856mm
âMain blade length: 380mm
âTail rotor diameter: 196mm
âTail blade length: 70mm
âMain shaft diameter: 8mm
âTail shaft diameter: 5mm
âColor: Red white/Yellow white
Recomended Parts(not included):
-1 x RadioLink AT9 2.4GHz 9CH Transmitter
-1 x 22.2V 1800mah 6S Lipo Battery
-3 x ALZRC 452 Swashplate servo
-1 x ALZRC 501 Tail servo
-1 x KBAR K8 3 Axis Gyro
Manual:
Packaging:
âDevil 380 FAST FBL KIT x 1
âALZRC Devil 380 ESC x 1
âALZRC Devil 380380 Motor x 1
The differences with the Devil 380 RC Helicopter: Most of the metal parts replaced with plastic parts and some parts more thin.
-Plastic Tail rotor control arm
