Description:
Item name: Omnibus F7 Flight Controller
Size: 36x36mm
Mounting hole: 30.5x30.5mm
Weight: 7.2g
Color: black
Color: black
Firmware: betaflight_3.2.0_OMNIBUSF7
Input voltage: 2-4S
Main control: STM32F745VET6 CortexM7 MCU+FPU, 462DMIPS LQFP-100
Sensor: MPU6000+ ICM-20608
OSD: AT7456E
Barometer: BMP280
Supports receiver: PPM/SBUS
ESC output signal: PWM, Oneshot125, Oneshot42, MULTISHOT, BRUSHED, DSHOT150, DSHOT300, DSHOT600
BEC: 5V/2A
LED_Strip port: with
Buzzer port: with
Current sensor port: with
Voltage sensor port: with
Features:
STM32 F745 MCU, runs betaflight_3.2.0_OMNIBUSF7.
Collected all of advantages of F4 flight controller.
Dual gyros make it needless to match new PID parameters when carrying gopro camera.
Dual sensors of MPU6000+ ICM-20608 both use SPI bus communication, high transmission rate.
Built-in BMP280 barometer.
Supports black box logging function (please add a SD card by yourself).
With LC filter, reduce the interference from motors.
Package included:
1 x Omnibus F7 flight controller
1 x 6 Pin * 1.0mm cable
1 x 8 Pin * 1.0mm cable
1 x 3 Pin * 2.54mm * 10 cable
