BlueArrow DPC-3 Digital Servo Program Card
Description:
Brand Name: BlueArrow
Item Name: Digital servo program card
Item NO.: DPC-3
Usage: Suitable for digital servo. (More details please refer to the manual)
Function:
Dead Band:
Set the smallest signal change width that the servo can response.
Stretcher:
Set position error magnification ratio.
Max. Duty:
Set the intensity of the motor drive. Max is 248.
Boost:
Set the pulse width of the motor from stationary to work.
Pulse Lower:
Set the pulse(Min). Recommended 900μs.
Pulse High:
Set the pulse(Max). Recommended 2100μs.
Left Range:
The angle from the middle position to the Min Pulse.
Right Range:
The angle from the middle position to the Max Pulse.
Neutral:
Set the middle position of the servo. Usually is 0.
Drive Frequency:
Motor drive frequency.
Inverter:
Reverse control bit about the servo.
Narrow Band:
Narrow (760μs) pulse servo.
English Manual,
Package Included:
1x Program card
1x USB
1x Cable (can switch JST1.0,1.25,1.5 plug servo)
