Specification:
Brand name: DALRC
Item name: F722 DUAL Flight Controller & Rocket 50A ESC
Flight Controller:
Size: 3.7.5*37.5mm
HTH Distance: 30.5*30.5 Φ4mm
MCU: STM32F722RGT6
Gyro: MPU6000(Smooth) and ICM20602(32K)
Flash: 16MB
BEC: 5V/2A 9V/1.5A
OSD: Support
Input voltage: 3-10S (10-50V)
Firmware: Betaflight DALRCF722DUAL
Weight: 7.4g
ESC:
Weight: 7.4g
ESC:
Con. Current: 50A
Peak. Current: 60A (10S)
Lipo: 3-6S
BEC: NO
Firmware: Blheli_32
Size: 37.5x37.5mm
Support DSHOT1200, PWM, Multishot, OneShot
Mounting hole: 30.5x30.5mm/Ф4mm
Weight: 16g
Package Included:
1 x F722 DUAL Flight Controller
1 x Rocket 50A Brushless ESC
4 x Silicon Damper Ball
1 x Rocket ESC connecting cable
1 x Rubycon 560uF 35v ZLH capacitor
