Overview:
Enjoy the flight more than build. The DTS GT200 is ready for race right after you open the box. Pilots need not to tune the quad but only install the receiver.
The 4S power system comprises of 2206-2500Kv naked-bottom motors for agile response and 30A ESCs with BLHeli-S and Dshot 600 compatibility.
An Omnibus F4 SD flight controller controls the quad comprehensively, when transmitting the user-configurable data to the on-screen display through the
Betaflight OSD (Version 3.2.4). The Runcam Eagle 2 Pro GWY Edition camera with 2.1mm lens transmits distinctive and clear video through the GWY variable
power video transmitter to a compatible 5.8GHz monitor or goggles. Furthermore, you can choose among 25, 200 or 600mW video transmitter power modes,
you can even change your band and channel directly from your transmitter or on the main control unit built on the GT200. All these incredible components are
implanted in this brand new impact-resistant main control unit which protects all essential electronics. This user-friendly unit can be easily accessed to USB ports,
and video transmitter can also be changed easily. The DTS GT200 is ready to slice through any FPV course. Before the flight, the only thing you need to do is
to install and charge a 4S 1500mAh > 50C battery as well as your receiver.
Pre-built and Professionally Tuned: Ready to go right out of the box
Completion Level: RFR (without Radio System, Charger, Battery)
Frame: 5mm Thickness 3K Carbon Fiber Frame
Rear: Reserve Gopro Mounting Seat
Wheelbase: 200mm
Flight Control: Omnibus F4 SD with BetaFlight (Version 3.2.4)
Video Tx: 25/200/600mW 48 Channel (A,B,E,FatShark ,Race Band ,Low Race)
Camera: Runcam Eagle 2 Pro Team GWY Edition camera with 2.1mm lens
ESC: 30A 4in1 BLHeli-S Brushless
Motor: 2206 2500kv Brushless
Propellers: 5"
Compatible Receiver: ≤40 x 24mm (L*W)
Weight: Approx. 340g (Without Battery)
Basic Flying Weight: 492g
Approximate Assembly Time: Less than 1 Hour
REcommended Parts(package not included):
Transmitter: 6+ channel Transmitter (Aircraft / Multicopter system)
Receiver: 6+ channel Receiver (DSM /SBUS signal)
Charger: LiPo Compatible 4S Battery Charger
Battery: 4S 1500mAh >50C LiPo Battery
Package included:
1 x DTS GT200 RFR
4 x 2206-2500Kv Brushless Motor
1 x 30A 4in1 BLHeli-S with Dshot 600
1 x Omnibus F4 SD Flight Control with BetaFlight Version 3.2.4
1 x 25/200/600mW Adjustable Video Transmitter
1 x RunCam Eagle 2 Pro GWY Edition FPV Camera
1 x Aluminum Spare Canopy
1 x Aluminum Motor Prop Nut Wrench Tool (for removing props and prop nuts from motors)
1 x User Manual
