Specification:
Brand name: EMAX
Item name: Pulsar 2306 Brushless Motor
KV | 1700KV | 2400KV |
Motor Dimensions | φ27.7*33mm | φ27.7*33mm |
Framework | 12N14P | 12N14P |
Bearing Shaft | 4mm | 4mm |
Idle Current(10V) | 0.9A | 1.6A |
Internal Resistance | 78mΩ | 45mΩ |
No.of cells | 3-6S | 3-4S |
Propeller | 5"-5.5" | 5"-5.5" |
Peak Current(6S/4S) | 34.4A | 41.3A |
Max.Power(6S/4S) | 867W | 694W |
Prop adapter shaft thread | M5 | M5 |
Shaft Thread | CW | CW |
Lead | 20#AWG 115mm | 20#AWG 115mm |
Weight | 31.7g(W/O Silicone Wire) | 31.6g(W/O Silicone Wire) |
Feature:
Precision bearing
Steel shaft
Anodizing
16*16mm hole pattern
Multi-strand winding
115mm 20 AWG silicone wire
Package lncludes:
1 x Pulsar 2306 Brushless Motor
5 x M3*7 Screw
5 x M3*6 Screw
1 x Aluminum M5 Nylock Nut
1 x Washer and Screw for Shaft
