Description:
The AFHDS 2A developed by FLYSKY is intended for all radio control models. It offers superior protection against interference while maintaining lower power consumption and highly reliable receiver sensitivity.
Â
Main Features:
Two-way Communication
Capable of sending and receiving data, the transmitter can receive data from the temperature sensor, barometer, accelerometer and etc.
Â
Multi-channel Frequency Hopping
Ranging from 2.408GHz to 2.475GHz, the bandwidth is divided into 135 channels to minimize the interference from other transmitters.
Â
Omnidirectional Antenna
The omnidirectional high gain antenna reduces interference while using less power and maintaining a reliable connection.
Â
Unique ID Recognition System
Each transmitter and receiver have its own unique ID. The paired units will connect automatically with each other for the second time.
Â
Low Power Consumption
It only consumes about one-tenth the power of a standard FM system, dramatically extending battery life.
Specifications:
FLYSKY FS - i6X Transmitter
Channels: 6 - 10 ( default: 6 )
Model type: fixed-wing airplanes / gliders / helicopters
RF channels: 135
Frequency range: 2.408 - 2.475GHz
Bandwidth: 500KHz
RF power: less than 20dBm
2.4GHz system: AFHDS 2A / AFHDS
Modulation: GFSK
Low voltage warning: less than 4.2V
DSC port: PS/2, PPM
Chargeable: no
Antenna length: 26mm ( dual antennas )
Weight: 392g
Power input: 4 x 1.5V AA ( 6V )
Display: STN LCD, 128 x 64 lattice, VA 73 x 39mm, with white backlight
Online update: yes
Certificate: CE0678, FCC
FLYSKY FS - X6B Receiver
Channels: 6 ( PWM ), 8 ( PPM ), 18 ( iBUS )
Model type: multirotor
RF range: 2.408 - 2.475 GHz
Brand width: 500KHz
Number of bands: 135
RF power: no more than 20dBm
Sensitivity: -95dBm
2.4GHz protocol: AFHDS 2A
Modulation type: GFSK
Stick resolution: 1024
Low voltage alarm: yes
DSC port: PPM / PWM / iBUS
Antenna length: 93mm ( dual antennas )
Power input: 4.0 - 8.4V
Online update: yes ( wireless )
Range: more than 300m
Weight: 4.5g
Size: 36 x 22 x 7.5mm
iBUS port: yes
Certificate: CE0678, FCC
Specification
General |
Brand: Flysky
Type: Transmitter Receiver Set |
|---|---|
Dimension and Weight |
Product weight: 0.392 kg
Package weight: 0.730 kg Product size (L x W x H): 17.40 x 8.90 x 19.00 cm / 6.85 x 3.5 x 7.48 inches Package size (L x W x H): 20.00 x 10.00 x 20.00 cm / 7.87 x 3.94 x 7.87 inches |
Package Contents |
Package Contents: 1 x Transmitter, 1 x Receiver |
