FPV Radio Telemetry 915MHz Air Ground Module


Main Features:
- Range of approx. 1 mile with supplied antennas
- Can be used with a bi-directional amplifier for even more range
- Demonstrated range of several kilometers with a small omnidirectional antenna
- With MAVLink protocol framing and status reporting
- Frequency hopping spread spectrum ( FHSS )
- Adaptive time division multiplexing ( TDM )
- Transparent serial link
- Support for LBT and AFA
- Open source firmware, configurable duty cycle
- Built-in error correcting code, up to 25 percent correction of data bit errors
- AT commands for radio configuration; RT commands for remote radio configuration
- Adaptive flow control when used with APM
- Based on the HopeRF HM - TRP radio module, featuring an Si1000 RF micro-controller

Specifications:
Frequency band: 915MHz
Receiver sensitivity: up to -117dBm
Range: 1 mile ( or more with bi-directional amplifier and omnidirectional antenna )
Transmit power: up to 500mW
Air data rate: up to 250kbps

Specification

General

FPV Equipments: Transmitter
Functions: Video

Dimension and Weight

Product weight: 0.0600 kg
Package weight: 0.0880 kg
Product size (L x W x H): 15.00 x 4.00 x 1.00 cm / 5.91 x 1.57 x 0.39 inches
Package size (L x W x H): 18.00 x 5.00 x 2.00 cm / 7.09 x 1.97 x 0.79 inches

Package Contents

Package Contents: 1 x Air Module, 1 x Ground Module, 2 x Antenna, 3 x Cable
