FrSky R9M 2019 900MHz Long Range Transmitter Module and R9 STAB OTA ACCESS RC Receiver with Mounted Super 8 and T antenna
â
âOVERVIEW:
| R9M 2019 900MHz Module | R9 STAB OTA Receiver | |||
| FrSky R9 and R9M radio control system is the first FrSky long range system which works in the frequency of 900MHz. The R9M module offers 4 switchable RF power outputs to so you can choose the appropriate power for different flight situations. Compared to another FrSky 2.4GHz long range receiver like the L9R, the R9 receiver has a longer operating range up to 10KM and above. Moreover, the R9 is also a redundancy receiver which can connect to another receiver to ensure the security of your aircraft. | R9 STAB OTA is a 900MHz long-range and stabilization receiver with a built-in 3-axis gyroscope and 3-axis accelerometer. | MULTIPLE FLIGHT MODES:R9 STAB OTA has 8 PWM channels, on traditional fixed-wing models it will support stabilization, automatic level, hover and knifes-edge flight modes. For delta wings and V-tail models, it supports stabilization and automatic level flight modes. | ACCESS PROTOCOL:R9 STAB OTA receiver implements the ACCESS protocol and brings the user improved performance and features. It supports wireless over-the-air firmware updates, making binding to receivers even easier as well as conveniently checking the current receiver firmware version. | CONFIGURATION PARAMETERS:Paired with a FrSky radio transmitter, the parameters can be adjusted conveniently through the LUA script. In addition, parameters may also be adjusted by FreeLink (PC) and FreeLink App (with AirLink S). |
Specifications:
âBrand Name: FrSky
âItem Name: R9M 2019 Module and R9 STAB OTA Receiver
âWeight: 150g
â
âR9 STAB OTA Receiver:
âDimension: 45.7*26.3*16.2mm
Weight: 18.6g
Numbers of Channel: 8/16CH (CH16 outputs RSSI)
Operating Voltage: DC 3.5V~10V
Operating Current: [email protected]
Measuring range of gyroscope: ±2000dps
Measuring range of acceleration: ±4g
Compatibility: R9M Lite/R9M/R9M 2019 with ACCST firmware,
R9M Lite/R9M Lite Pro/R9M 2019 with ACCESS firmware
â
ACCESS protocol and supports OTA functions
900MHz/868MHz long-range with low latency
Built-in 3-axis gyroscope and 3-axis accelerometer
Support S.Port
Supports quick configuration for setting multiple flight modes (quick mode)
Detachable Ipex1 connector antenna
Multiple configuration methods (LUA script and FreeLink)
âR9M 2019 900MHz Module:
âCompatibility : R9 series
Vin Voltage Range: 6.5V-13V
External Power Supply: 6.5V~13V
Telemetry Interface: Smart Port
Upgrade Interface: Smart Port
Modulations: PXX or CPPM (auto-detected)
â
900MHz/868MHz working mode
Long range, low latency and high precision RC system
4 Optional RF power (Non-EU Version)
Telemetry modeï¼25mWï¼/non-telemetry modeï¼200mW / 500mWï¼ (EU Version)
RF Power (Flex): 10mW/ 100mW/ 500mW/ 1W (telemetry supported for all levels)
Smart Port enabled and support telemetry data transmission
Package included:
1 x R9M 2019 module with mounted Super 8 antenna
1 x R9 STAB OTA receiver with mounted Ipex4 T antennaâ
