FrSky RB30 24CH Dual Power Triple Receive Signal Redundancy Module Built-in Gyroscope Sensor Non-contact NFC Switch for RC Drone
SPECIFICATIONS:
Brand Name: FrSky
Item Name: RB30 Module
Weight: 100g
Dimension: 114.4*73.4*18.7mm
Number of Servo Connector: up to 24
Operating temperature:-20â~75â
Recommended input voltage range : DC 11~26V
OUTPUT1&OUTPUT2ï¼SBEC OUTPUT, Continuous Current: 2*15A@5~8.4V
FEATURES:
Dual Power & Triple Receiver Guarantee
High-voltage Servo Supported (Up to 24 PWM servos)
Overload Protection on Each Channel
Channel 1 â 8 with Current Detection
Supports Stabilization Function with Built-in Gyroscope Sensor
Multiple configuration methods (Lua script and FreeLink)
Compatible with FrSky S.Port products
Various S.Port Telemetry Feedbacks (Voltage, Current, Power Consumption, etc.)
Black Box Data Record Function
Non-contact NFC Switch Function
The upgraded redundancy hub:
Previous redundancy bus models offered a dual-power with a dual-receiver design, the RB30 allows the user to use a triple redundancy by adding a multiplex port (RX3 IN / SBUS Out) and uses a set of standard XT30 plugs which provides a safe and efficient way to provide power.
Up to 24 PWM channels with overload protection:
The RB30 supports connecting up to 24 high-voltage servos with overload protection added to each output channel. Eight of the channels (CH1-8) are equipped with current sensors.
The diversified sensors:
The RB30 is an extensive sensor module with a built-in gyroscope that supports model stabilizing functions and includes other diversified telemetry feedback like the voltage, power consumption, altitude, and a lot more. It can be used as an alternative to using a GR or S series receiver.
NFC Switch & Automatic data logging functions:
The non-contact NFC switch is an external device that enables the power to be switched on/off on command without the need to plug/unplug the battery connections. Once power is connected, the black-box function is automatically activated and immediately starts recording the data.
Package Included:
1 x RB30 Module
