The VS600 is the first video transmitter developed by FrSky team. The 48 channel Video Transmitter features 3 power settings (25mW/200mW/600mW) and a very useful Pit Mode that allows the users to power it up at a low power (1mW) to change settings and conduct tests during racing events without the fear of interfering with live channels. Selecting your Operating Bands and Channels are easily adjusted with two push buttons and the indicator LEDs are easy to read. The Pigtail Antenna with UFL connection can easily be placed in the optimal location. Uniquely the VS600 has 2 different mounting hole options in 1 board, 31mm spacing and 20mm spacing. One of the most useful features is that all the setting can be fully adjust via OpenTX Lua Script and the FrSky FreeLink App.
Specification:
Transmission Frequency: 5.8 GHz
Available Channel: 48
Operating Voltage: DC 7V~28V
Operating Current: 260mA@12V (200mW)
Transmission Power: 1mW(Pit mode) / 25mW/ 200mW/ 600mW
Dimension Outer Frame
Inner Frame
Weight: 3.7g
Features:
Pit Mode supported
Optional installation position
Clear LED indication
Adjustable operating bands and channels (push buttons and with Lua Script, FreeLink App)
Switchable transmission power
Pigtail antenna
Package Included:
1 x VS600 FPV Transmitter
