Specification:
Brand Name: GEELANG
Model: GL1204
Item Name: 1204 4500KV 3-4S / 5000KV 2-4S Brushless Motor
KV: 4500KV / 5000KV ( Optional)
Input Voltage: 3-4S ( 4500KV); 2-4S ( 5000KV)
Quantity: 1 PC
Configuration: 9N12P
Stator Diameter: 12mm
Stator Length: 4mm
Shaft Diameter: 1.5mm (2mm inside)
Motor Dimension: 15.26x11.9mm
Idle Current (Io/10V): 0.8A
Max. Current(5S): 10A
Max. Con. Power(5S): 150W
Motor Resistance: 100mΩ
Weight: 6g approxi.
Application: original part for GEELANG Anger 85X FPV Drone
Package Included:
1x GL1204 Motor
