GEPRC GEP LSX4 LSX5 LSX6 205mm 230mm 265mm Carbon Fiber FPV Racing Frame with PDB Board - 49.99 €

GEPRC GEP LSX4 LSX5 LSX6 205mm 230mm 265mm Carbon Fiber FPV Racing Frame with PDB Board

Specification Item name GEPRC Item model LSX4/LSX5/LSX6 GEP-LSX4 Weight: 109g
Wheelbase: 205mm
Props Size: 4inch
Size: 165*200mm
Arms board: 4mm
Side board: 2mm
Other board: 1.5mm

Recommend parts:
Motor: 2204/2205
Esc: 20A-30A
Props: 4inch
Battery: 3S 1300mAh~4S 1300mAh GEP-LSX5 Name: GEP-LSX5
Weight: 114g
Wheelbase: 230mm
Props Size: 5inch
Size: 178*222mm
Arms board: 4mm
Side board: 2mm
Other board: 1.5mm

Recommend parts:
Flight Controller: F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC: 20A-35A
Propeller: 5inch
Battery: 3S 1300mAh ~ 4S 1500mAh GEP-LSX6 Name: GEP-LSX6
Weight: 123g
Wheelbase: 265mm
Props Size: 6inch
Size: 200*250mm
Arms board: 4mm
Side board: 2mm
Other board: 1.5mm

Recommend parts:
Flight Controller: F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC: 30A-40A
Propeller: 6inch
Battery: 3S 1300mAh ~ 4S 1800mAh
Feature:
1. Aviation aluminum # 7075 high-precision CNC fuselage, very strong resistance to blast
2. 3K high strength carbon board to ensure that the frame is strong
3. An aluminum alloy structure, binding the four machine arm will not shift
4. The structure of SX, suitable for racing
5. Reasonable gopro, runcam position, convenient video
6. 13.5 mm wide, 4 mm thick arm design, small wind resistance coefficient
7. 5 inch wheelbase 230 mm, 4 "wheelbase 205 mm, 6 inch wheelbase 265 mm, have wider air through
8. The YFS screws, 12.9 level of hardness
9. support HS1190 HS1170, Swift
10. The motor position widened, home is not easy to hit the motor
11. The camera is adjustable, 0 to 60 degrees
12. With the kits: a piece of PDB panels, integrated XT60, BEC (5/12v output)

Package Included:
1 X Frame Kit
1 X PDB board
