Specification:
Brand Name: GEPRC
Model: GEP-SPAN-F722-BT
Item Name: Dual Gyro F7 OSD Bluetooth Flight Controller & 50A BL_32 3-6S ESC Stack
MCU: STM32F722RET6
IMU: 2x ICM20689 (SPI)
Input Voltage: 3-6S
Blackbox: 32Mb onboard Flash
OSD: BetaFlight OSD w/ AT7456E chip
BEC: 5V 3A
Integrated with LC Filter
Firmware: EXF722DUAL
Bluetooth Configuration: SpeedyBee APP
Size: 36x36mm ( M4; M3 if using anti-vibration standoff)
- 5 UARTS
- 8 Motor Signal Port
- Weight: 6.5g
- Support Sbus, PPM, CRSF, DSMX, iBus Receiver
50A BLheli_32 4in1 ESC
MCU: STM32FO51K86 (32bit 48mHz)
Continuous Current: 50A
Peak Current: 55A (5S)
Current sensor: Supported
Telemetry: Supported
Support DSHOT1200/DSHOT600, PWM, Multishot, OneShot
Firmware Version:GEPRC-BL32-4IN1
Input Voltage: 3-6S Lipo
Package Included:
Package Included:
1x F7 Flight Controller Board
1x 50A 4In1 ESC Board
1x 8pin Cable
4x 4pin Cable
1x 35v 220uf Capacitor
1x XT60 Power Cable
12x Anti-vibration Balls
4x M3*25 Screw
4x M3*30 Screw
8x M3 Nylon Nut
