Specification:
Brand Name: HAOYE RC
Model: X1
Item Name: 229mm Wheelbase F4 4S 5 Inch FPV Racing Drone
Version: PNP ( Without Receiver)
Wheelbase: 229mm
HAOYE X1 229mm Frame | Wheelbase: 229mm âMaterial: Carbon Fiber âArm Plate Thickess: 5mm âOther Plate Thickness: 2mm âStandoff Height: 25mm âDimension: 187x206mm âWeight: 128g |
Omnibus F4 Flight Controller | Omnibus F4 Flight Controller - Betaflight OSD |
45A 4in1 Brushless ESC | Con. Current: 45A Burst Current: 50A (5S) Firmware: BLHeli_S |
RCINpower EX2306 2550KV Motor | Input Voltage: 3-5S Configuration: 12N14P Stator Diameter: 23mm Stator Length: 6mm Shaft Diameter: 5mm Mounting Hole: 16x16mm |
Gemfan 5166 3-Blade Propeller | Color: Transparent Gray Quantity: 2 CW & 2 CCW |
Panda RC VT5804M V2 5.8G 48CH 600mW VTX | Brand Name: Panda RC Model: VT5804M V2 Item Name: 5.8G 48CH 0/25/100/200/400/600mW VTX Input Voltage: 7-24V Output Power: 0/25/100/200/400/600mW ( Switchable) Channels: 48 inc 8 racing channels Power Consumption: 260mA@12V/600mW Dimensions: 36x36x5mm Weight: 6g without antenna |
Caddx Ratel 1200TVL FPV Camera | Lens: 2.1mm Image Sensor:1/1.8" Inch starlight HDR sensor Horizontal Resolution:1200TVL FOV: 180 Degree Min. Latency: 8ms TV System:NTSC & PAL (changeable) Image: 16:9 & 4:3 (changeable) WDR:Super WDR (HDR) Camera OSD:Separate OSD DNR:3-DNR Dimensions:19mm*19mm*19mm Wide Power Input:DC 5-40V |
Recommend Lipo Battery ( NOT Included) | Recommend 4S 1300-1500mAh Lipo Battery |
Package Included:
1x HAOYE RC X1 229mm FPV Racing Drone
1x Battery Strap
