Specification:
Brand name: HBFPV
Item name: XF40-GT 77mm 2-3S Whoop
Max Prop: 40mm (1.6 inch)
Wheelbase: 77mm
Thickness of Carbon Fibre: 1.0mm
Material of Ducts: Enhanced PP
Material of Canopy: Enhanced Nylon Plastic
Power Supply: 2-3S
Weight: 47g (without BAT)
Hovering Throttle: 30-33% (with 3S 300mAh)
Recommend BAT: GNB 3S 300mAh / GNB 3S 350mAh
FC: F4 2-4S 5V 2A BEC built-in OSD
ESC: 12A (2-4S ESC) BLHeli_S 4in1 DShot600
| Flight Controller |
Size: 28.5mm x 28.5mm Mounting hole: 25.5mm x 25.5mm MCU: STM32 F4 Gyroscope: MPU6000 BEC: 5V/2A Input Voltage: 2-4S Lipo Built-in Betaflight OSD |
| ESC |
Firmware: BLHELI_S Input Voltage: 2-4S Lipo Continuous current: 12A Pe ak Current: 13A(3 seconds) |
| Motor |
Prop: GF1636-4 40mm 4-blade propeller Cam: EOS2 1200TVL camera VTX: Pit-25-100-200mW with IRC Tramp |
| VTX |
Output power: Pit-25-100-200mW Control mode: BF OSD control (IRC Tramp) Video system: NTSC/PAL Battery: 5V Frequency: 5.8GHz 6 bands 48 channels, with RaceBand: 5362-5945MHz |
Manual Donwload:
FC & ESC & VTX Manual
IRCTramp/SmartAudio OSD Manual
Receiver Binding Manual
Package Included:
PNP Package Included:
1x XF40 GT FPV Drone
1x Propeller Disassemble Tool
1x Screwdriver
BNF Package Included:
1x XF40 GT FPV Drone
1x Micro Receiver (FrSky Pro D8/ DSMX Pro/ FS-RX2A / AC900 for F utaba SFHSS / FrSky D16) Optional
1x Propeller Disassemble Tool
1x Screwdriver
