Hobbywing XRotor Omnibus F4 Flight Controller Built-in OSD Support DShot1200 TF-Card Insertion - 43.99 €

Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)

Free shipping aviable, Registered postage from 25 €

Hobbywing XRotor Omnibus F4 Flight Controller Built-in OSD Support DShot1200 TF-Card Insertion

Diagram Picture:

Specification:
Brand Name: Hobbywing
Model: Rotor F4
Item Name: Omnibus F4 Flight Controller Bulit-in OSD
MCU: STM32 F405 MCU
MPU: MPU6000 SPI Sensor
Firmware Version: OMNIBUSF4SD
Size: 35x35mm
Mounting Holes: 30.5x30.5mm
-Support PWM, Oneshot42, Oneshot125, Multishot,
Dshot150, Dshot300 and Dshot600
-Compatible with PPM, Spektrum, SBUS, SUMD, SUMH, XBUS,
IBUS, JETIEXBUS, CRSF and SRXL Transmitter

Features:
-STM32 F405 MCU allows the FC to run the PID looptime and gyro with higher frequency.

-SPI Sensor MPU6000 includes an accelerometer and a gyro.
-Onboard OSD microchip which supports the DMA mode allows users to adjust its parameters via
the Betaflight software. (Note: the OSD is controlled by the F4 MCU.)
-The FC which supports Betaflight firmware & allows parameter adjustment via Betaflight software
is more applicable to FPV race.
-TF-card which can record and save more flight/back box data allows users to adjust the setup of
their aircraft easily.
-Compatible with various receivers like SBUS, SUMH, SUMD, SPEKTRUM1024/2048, XBUS, PPM
and etc.
-LED strip signal output port allows users to adjust the color & flash mode of the LED strip via the FC.
-Volt/Amp monitoring port allows users to check the battery voltage ( VBAT+ port ) and current
(CRT port ) (extra current meter is needed).
-Buzzer output port allows users to connect external buzzer(s) to the FC for warning or informing
the flight status of the aircraft.
-Micro USB port allows users to connect the FC to a PC to flash firmware and adjust parameters.

Package Included:
1x F4 Flight Controller
