This product is used in Pixhawk and pixhack flight controller .The LED light control board is connected to the I2C interface of the Pixhawk flight controller. It can be used to change the flashing form of the light according to the flight control status.
Two of the LED lights are used to indicate the direction of the aircraft head, and the color of the LED light can be arbitrarily modified by the dial switch. The other two LEDs are used to indicate the state of the aircraft, which is consistent with the onboard LED function on the flight controller.When the communication line of this module is connected to the I2C interface of pixhawk flight control, the board LED will be off..
Specification:
Item name: LED Light Board
LED lamp rated voltage: 5V
BEC buck module input voltage: 7V~28V
BEC step-down module output voltage: 5V
Switch color selection: red, green, blue, purple, yellow, blue, white
LED line length 30cm
Note: Before power-on, you need to connect 4 LED lights to the control panel, otherwise the LED lights may burn out.
The indication function of the LED light is as follows:
Red and blue flashing - flight control initialization
Blue flashing - not unlocked, no GPS lock
Solid blue - unlocked, no GPS lock
Flashing green - not unlocked, GPS locked
Green is always on - unlock, GPS lock
Double flash yellow - unlock failed
Single flashing yellow - remote control lost
Fast yellow flash (with buzzer drip) - low voltage
Yellow and blue alternately flashing - GPS failure
Purple and yellow alternately flashing - barometer malfunction
Yellow and red alternately flashing - EKF error
Package Included:
1 x LED Light Board set
