Introduction:
- The iFlightCineBee 4K is an upgrade of the popular CineBee HD,
created to record professional grade 4K high-resolution video for sport and commercial use.
created to record professional grade 4K high-resolution video for sport and commercial use.
- Our target was pretty clear, create a lightweight, durable but jellofree whoop that can shoot high-quality videos.
- We decided to use a combination of carbon, plastic, and TPU to have a rigid bottom plate that doesn't oscillate,
with still crash resistant abilities and integrated prop guards giving the whole frame strength.
The stack is soft-mounted, the cam is soft-mounted, the motors run smooth
- keep your props in a good condition, and you won't have to worry about jello!
Specification:
Brand Name: iFlight
Model: Cinebee 4K
Item Name: 107mm Wheelbase F4 OSD 2-3S Whoop FPV Racing Drone
Frame Wheelbase: 107mm
- We decided to use a combination of carbon, plastic, and TPU to have a rigid bottom plate that doesn't oscillate,
with still crash resistant abilities and integrated prop guards giving the whole frame strength.
The stack is soft-mounted, the cam is soft-mounted, the motors run smooth
- keep your props in a good condition, and you won't have to worry about jello!
Specification:
Brand Name: iFlight
Model: Cinebee 4K
Item Name: 107mm Wheelbase F4 OSD 2-3S Whoop FPV Racing Drone
Frame Wheelbase: 107mm
Frame Wheelbase: 107mm
- Build Weight: 106 grams
- SucceX Micro F4 16x16 Tower 2-4S
- iFlight 1104 9500kV motors (1.5mm shaft)
- Caddx.us Tarsier 4K 1200TVL Dual Lens
- Dalprop Q2035 4-blade
- iFlight Prop Guards 2 inch
Features:
|
iFlight SucceX Tower - F4 Flight Controller AIO OSD BEC |
-STM32F411
-Input voltage 2-4S LIPO
-Gyro: MPU6000
-2x UART ports
-4x motor outputs
-OSD inbuilt
-No Blackbox FLASH
-BEC 5V 2A cont.
-Size: 21mm*21mm
-Mounting holes: 16*16
-Weight: 2.5g
-BF target : MATEKF411
|
|
iFlight SucceX Tower - Micro 12A BLheli_S 4in1 ESC |
Input voltage : 2-4S LIPO
Continuous current: 12A
MCU: BB21F16G
BEC : None
ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
Size: 23mm*21mm
Mounting hole 16*16mm
Weight: 2.7g
|
|
iFlight SucceX Tower - Mirco VTX PIT/25/100/200mW |
-Power : PIT/25/100/200mW
-Antenna interface : IPEX (UFL)
-Telemetry: IRC Tramp
-Size: 17mm*27mm
-Mounting holes: 16*16mm
-Weight: 1.6g
-VTX can be conveniently set up in your OSD |
|
iFlight 1104 9500kV Motor (1.5mm shaft) |
Configuration: 9N12P
Stator Diameter: 11mm
Stator Length: 4mm
Shaft Diameter: 1.5mm
Idle Current(10V): 1.25A
Max. Con. Power (180S): 59.2W
Internal Resistance: 152mΩ
Max. Current(180s): 8A
Motor Dimension(Dia*Len):14.3x11.8mm
Weight: 5.4g
-We offer several motor setups to fit your desired performance, equipment or just preference.
- 2S , 3S will be available.
|
|
Caddx Tarsier 4K 1200TVL Dual Lens Camera |
Lens: Dual Lens F2.8/12Mega Audio: Dual Digatil Mic FOV: 4K F2.8, FOV150 Degree (16:9); FPV FOV165 Degree (4/3) Weight: 18g More Details, click here |
| Dalprop Q2035 4-blade Propeller |
Brand Name: DALProp Item Name: 2035 2x3.5 4-Blade Propeller Quantity: 2 CW + 2 CCW Color: Blue |
| Receiver |
PNP ( Without Receiver) BNF ( with Optional Receiver) |
|
Lipo Battery ( NOT Included) |
All version doesn't include battery. Recommend using 2-3S 300mAh-600mAh Lipo |
Features:
- 4K 30fps, 2.7k 60fps, EIS (image stabilization)
- 1200TVL <10ms low latency FPV cam
- Ultra-light but high performance
- JELLOFREE durable carbon/plastic construction
- No props or prop guards in view
- Upgradeable, versatile, futureproof
Pacakge Included:
1x iFlight Cinebee 4K FPV Racing Drone
Pacakge Included:
1x iFlight Cinebee 4K FPV Racing Drone
