iFlight TITAN H3 HD 150mm Full 3K Carbon Fiber 3 Inch Frame Kit Compatible DJI Air Unit for RC Drone FPV Racing - 36.00 €

Specification:

Brand Name: iFlight

Model: TITAN H3 HD

Item Name: 150mm Wheelbase 3 Inch Racing Frame Kit

Wheelbase: 150mm

Material: 3K Carbon Fiber

Arm Plate Thickness: 3mm

Upper Plate Thickness: 2mm

Bottom Plate Thickness: 2mm

Side Plate Thickness: 1.5mm

Standoff Height: 28mm ( M2)

Size: 122x87mm

Weight: 46.5g

Features:

-Full 3K Carbon Fiber Frame

-TPU bracket protect to crash Air Unit Module

-150mm wheelbase, 46.5g

-Popular H style configuration, prop in View

-Fits 16*16/20*20/30.5*30.5mm stacks

Recommend Parts:

Flight Controller: 16x16/20x20/30.5x30.5mm F3/F4/F7 Flight Controller

Brushless Motor: 12XX / 14XX Series Motor ( 9x9mm Hole)

Brushless ESC: 20-50A ESC

Propeller: 30xx 3 Inch Propeller

FPV Camera: 19mm / 20mm Width

Lipo Battery: 4S 650-850mAh Lipo

The following Parts are Compatible: ( NOT Included)

FC & ESC: HIFIONRC F722Pro F7 FC & 45A BL_32 3-6S ESC

Brushless Motor: iFlight XING 1404 4600KV 3-4S Motor

Propeller: HQProp T3X3X3 3030 3-blade 3 Inch Propeller

VTX & Camera: DJI Digital FPV System Air Unit & Goggle Combo

Lipo Battery: Gaoneng GNB 14.8V 650mAh 80C/160C 4S XT30 Plug Lipo Battery

Package Included:

1 x TITAN H3 HD Frame

1 x Screw Bag

1 x TPU Camera mount

1 x TPU DJI Air Unit Bracket Mount

1 x TPU DJI Air Unit Antenna Mount

4 x 24.5mm*5mm Motor Wire Shield

2 x Antenna Protective Tube with caps

2 x Anti-slip battery pads

2 x Battery Straps 15x200mm
