Specifications:
General
Wheelbase: 86mm
Flight controller: F3 with integrated OSD, race timer and BEC
Processor: STM32F303 MCU
IMU: MPU6000
Brushless motor: 1104 7500KV
ESC: BLHeli - S 10A DShot ESC, compatible with 2S LiPo
AV transmitter: 5.8G 32CH 25mW
FPV distance: 200m ( free of obstacles )
Receiver: FrSky D8
FPV Camera
Sensor: 1/4 inch CMOS
Resolution: 600TVL
Min. illumination: 0.5 lux
SNR: more than 48dB
Gamma: 0.45
TV system: PAL
Refresh rate: 50fps
Shutter speed: 1/50 - 1/100,000s
Working temperature: -40 to 85 Deg.C
White balance: auto
Video output: 1Vp-p 75 ohm
Synchronization: internal
Color: yes
Recommended Power Source ( not included ):
Battery: 2S 500mAh 25C LiPo
Specification
General |
Type: Frame Kit
Version: BNF |
---|---|
Motor |
Model: 1104
Motor Type: Brushless Motor KV: 7500 |
Flight Controller |
Flight Controller Type: F3 |
Camera |
Video Resolution: 600TVL
Video Standards: PAL Sensor: CMOS |
Electronic Speed Controller |
Firmware: BLHeli-S
Continuous Current: 10A |
Dimension and Weight |
Product weight: 0.0780 kg
Package weight: 0.1870 kg Product size (L x W x H): 12.00 x 12.00 x 6.00 cm / 4.72 x 4.72 x 2.36 inches Package size (L x W x H): 15.00 x 14.00 x 7.00 cm / 5.91 x 5.51 x 2.76 inches |
Package Contents |
Package Contents: 1 x Frame Kit, 4 x Motor, 1 x F3 Flight Controller, 1 x ESC Set, 1 x Mini FPV Camera, 1 x Protective Cover, 4 x Propeller |
