Specifications:
Aircraft
Aircraft body weight: 425g
Diagonal size: 280mm ( including propellers )
Takeoff weight: 1.8kg
Max. ascent speed: 2.5m/s
Max. descent speed: 2.5m/s
Max. speed: 10m/s
Max. service ceiling above sea level: 4000m
Max. Flight time: 28mins ( FPV version ), 22mins ( aerial version )
Operating temperature: 0 to 40 Deg.C
Positioning system: GPS + GLONASS
Hover accuracy: + / - 1.5m
Propeller model: 7340
Transmitter
Operating frequency: 2.400 - 2.483GHz, 5.725 - 5.825GHz
EIRP: 2.400 - 2.483GHz: 26dBm ( FCC ), 17dBm ( CE ); 5.725 - 5.825GHz: 28dBm ( FCC ), 14dBm ( CE )
Operating temperature: 0 to 40 Deg.C
Image output: WiFi ( RD13 ) 2.5mm headphone jack ( RA13 )
Battery: 3.7V 2200mAh 1S LiPo ( built-in )
Operating current / voltage: 3.7V 0.5A
Charge time: 90 minutes
Operation time: 8 hours
Gimbal
Stabilization: 3-axis ( pitch, roll, yaw )
Controllable range: +20 to -90 degree
Weight: 170g ( with camera )
Charger
Input: 100 - 240V 50 / 60Hz 2.0A ( max. )
Output 1: 14.8V DC, 4.7A ( max. )
Output 2: 5.0V DC, 2.0A ( max. )
Rated power: 70W
Battery
Capacity: 3600mAh
Voltage: 14.8V
Battery type: 4S LiPo
Energy: 54Wh
Weight: 190g
Max. charging power: 70W
Operating temperature: 0 to 40 Deg.C
Specification
General |
Brand: JYU
Type: Outdoor,Quadcopter Model: Hornet 2 Features: Brushless Version,No camera,Radio Control Motor Type: Brushless Motor Functions: Automatically Following,Forward/backward,Point of Interest,Sideward flight,Turn left/right,Up/down,Waypoints Size: Medium Satellite System: GLONASS,GPS Built-in Gyro: 6 Axis Gyro Material: Electronic Components,Plastic Kit Types: RTF Level: Beginner Level |
---|---|
Connectivity |
Remote Control: 2.4GHz Wireless Remote Control
Channel: 12-Channels Radio Mode: Mode 2 (Left-hand Throttle) Control Distance: Above 800m Detailed Control Distance: 1000m Compatible with Additional Gimbal: Yes Transmitter Power: Built-in rechargeable battery Model Power: Built-in rechargeable battery |
Battery |
Battery: 3600mAh 14.8V 4S LiPo
Flying Time: About 28mins Charging Time.: 70mins Battery Weight: 190g |
Camera |
Camera Pixels: 0 ( no camera ) |
Dimension and Weight |
Package weight: 3.2400 kg
Product size (L x W x H): 23.30 x 23.30 x 17.20 cm / 9.17 x 9.17 x 6.77 inches Package size (L x W x H): 36.00 x 33.80 x 18.80 cm / 14.17 x 13.31 x 7.4 inches |
Package Contents |
Package Contents: 1 x Aircraft Body ( Battery Included ), 1 x Transmitter ( Battery Included ), 1 x Charger, 1 x Power Cable, 1 x USB Cable, 2 x Landing Gear, 4 x Lamp Cover, 4 x Propeller Guard, 8 x Propeller, 1 x English Manual |
