Description:
KingKong 110GT 117mm mini FPV racing drone uses the more powerful 1105 8500KV brushless motors, the superior 4-in-1 BLHeli - S 10A DShot ESC, and the 35C high discharge rate LiPo battery. KingKong 110GT allows you to fly swiftly and steadily both indoors and outdoors; enjoy the fascinating panoramic view with the 800TVL HD CMOS camera. Put the impact-resistant canopy backward, and you will be able to update / maintain the components inside.
Main Features:
â Micro F3 6DOF flight controller with 32-bit STM32F303 MCU and MPU6050
â 4-in-1 BLHeli - S 10A ESC supports the latest DShot digital signals etc.
â Furious flying speed - 1105 8500KV high PRM brushless motors and 35C LiPo
â 800TVL HD FPV camera, 150-degree FOV, 5.8G 16CH 25mW video transmitter
Specifications:
Wheelbase: 117mm
Weight: 63.7g ( not including battery )
Material: carbon fiber chassis + ABS canopy
Chassis thickness: 2mm
Brushless motor: 1105 8500KV
ESC: 4-in-1 BLHeli - S 10A
Flight controller: micro F3 6DOF
Propeller: 2840 three-blade
Camera: 800TVL CMOS
Field of view: 150 degree
Battery: 7.4V 350mAh 35C LiPo ( included )
Different Versions:
PNP: no receiver
ARF FrSky: FrSky XM 2.4GHz 16CH receiver
ARF FLYSKY: FLYSKY FS - RX AFHDS 2A 8CH receiver
ARF DSM2: DSM2 2.4GHz 8CH receiver
ARF Futaba: FM800 8CH receiver, compatible with Futaba FASST
Note:
The color ( red, yellow, white ) of the propeller will be shipped at random.
Specification
General |
Brand: KingKong
Type: Frame Kit Version: PNP |
|---|---|
Motor |
Model: 1105
Motor Type: Brushless Motor KV: 8500 No. of Cells: 2 - 3S |
Flight Controller |
Flight Controller Type: F3 |
Camera |
Video Resolution: 800TVL ( horizontal )
Sensor: CMOS |
Electronic Speed Controller |
Firmware: BLHeli-S
Functions: DShot150,DShot300,DShot600,Multishot,Oneshot125,Oneshot42 Input Voltage: 2 - 3S |
Battery |
Battery (mAh): 350mAh
Battery Coulomb: 35C Flying Time: 6-10mins Charging Time.: about 1 hour |
Dimension and Weight |
Product weight: 0.0637 kg
Package weight: 0.4550 kg Package size (L x W x H): 16.60 x 12.60 x 6.20 cm / 6.54 x 4.96 x 2.44 inches |
Package Contents |
Package Contents: 1 x Frame Kit ( Battery Included ), 1 x USB Cable, 1 x Battery Strap, 6 x Propeller, 4 x Propeller Guard, 1 x Spare Canopy, 1 x Connection Cable, 1 x Pack of Screws |
