Description:
This racing drone with a wheelbase of 136mm, is an excellent UAV for players. It has a highly integrated flight control system which consists of F3 flight controller and the 4-in-1 brushless BLHeli - S 10A ESC. In addition, the 25mW / 100mW 16CH video transmitter has been integrated into the flight controller, making it even lighter and more compact.
Specifications:
Wheelbase: 136mm
Weight: about 85.3g ( without battery and receiver )
Flytower: PIKO BLX ( F303CC + MPU6000 ) + 4-in-1 10A BLHeli - S
VTX: Q100 VTX ( 25mW / 100mW 16CH )
Camera: micro swift 2 ( 600TVL CCD 160 degree NTSC )
Motor: XT1104 - 7500KV ( 2 - 3S )
Prop: 4 pairs of 2840
Battery: 7.4V 550mAh 80C ( included )
Receiver: XM ( Frsky ), FS - RX2A ( Flysky ), DSM2 ( Spektrum ) ( option )
F3 Flight Controller
IMU: MPU6000
OSD: built-in
Camera
Resolution: 600TVL
Sensor: CCD
Video standard: 160 degree NTSC
Note
The KINGKONG will change its brand name to LDARC, the "LDARC" will replace "KINGKONG" to be showed on future products and advertising.
This racing drone with a wheelbase of 136mm, is an excellent UAV for players. It has a highly integrated flight control system which consists of F3 flight controller and the 4-in-1 brushless BLHeli - S 10A ESC. In addition, the 25mW / 100mW 16CH video transmitter has been integrated into the flight controller, making it even lighter and more compact.
Specifications:
Wheelbase: 136mm
Weight: about 85.3g ( without battery and receiver )
Flytower: PIKO BLX ( F303CC + MPU6000 ) + 4-in-1 10A BLHeli - S
VTX: Q100 VTX ( 25mW / 100mW 16CH )
Camera: micro swift 2 ( 600TVL CCD 160 degree NTSC )
Motor: XT1104 - 7500KV ( 2 - 3S )
Prop: 4 pairs of 2840
Battery: 7.4V 550mAh 80C ( included )
Receiver: XM ( Frsky ), FS - RX2A ( Flysky ), DSM2 ( Spektrum ) ( option )
F3 Flight Controller
IMU: MPU6000
OSD: built-in
Camera
Resolution: 600TVL
Sensor: CCD
Video standard: 160 degree NTSC
Note
The KINGKONG will change its brand name to LDARC, the "LDARC" will replace "KINGKONG" to be showed on future products and advertising.
Specification
General |
Brand: KingKong
Type: Frame Kit Version: BNF |
|---|---|
Motor |
Motor Type: Brushless Motor
KV: 7500KV |
Flight Controller |
Flight Controller Type: F3 |
Remote Controller Specifications |
Channel: 16CH
Protocol: DSM2/DSMX,Flysky,FrSky |
Camera |
Video Resolution: 600TVL
Video Standards: NTSC Sensor: CCD |
Dimension and Weight |
Product weight: 0.0853 kg
Package weight: 0.3090 kg Product size (L x W x H): 13.60 x 13.60 x 4.00 cm / 5.35 x 5.35 x 1.57 inches Package size (L x W x H): 16.60 x 12.60 x 6.00 cm / 6.54 x 4.96 x 2.36 inches |
Package Contents |
Package Contents: 1 x RC Drone, 1 x Receiver, 4 x Pair of Propellers ( White and Yellow ), 4 x Protective Guard, 4 x Motor Protective Seat, 1 x 7.4V 550mAh 80C Battery, 1 x 5D - OSD Menu Cable, 1 x Unloading Paddle, 1 x USB Cable, 1 x Rubber |
