Specification:
Brand Name: LDARC
Model: ET75 FPV
Item Name: 74mm F4 OSD FPV Racing Drone w/ Runcam Nano 2 Camera
Version: PNP ( Without Receiver) ; BNF ( With AC2000 Receiver)
Drone Wheelbase:74mm
Weight: 41.7g ( without battery)
F4 OSD Flight Controller |
Brand Name: LDARC Firmware: MATEKF411 MCU: STM32F4AA MPU: MPU6000 BEC: 5V 1.5A Onboard Current Sensor Onboard ESC Support SBUS DSM2/X iBUS Receiver |
Onboard 12A BLheli_S ( G_H_30) 4in1 ESC |
Con. Current: 12A Max. Current: 20A Support 2-4S Lipo Firmware: BLheli_S |
Onboard AC2000 Receiver ( Only BNF Version has) |
Item Name: AC2000 Receiver
Rated voltage: 4.0V~6.0V
Support S-FHSS(8 CHs)/D16 non-EU(14 CHs)/D16 EU-LBT(14 CHs) three modes, output S.BUS signal
Perfect fit high reliability medium and small size drone
The channel 16 of S.BUS value is real-time RSSI, BETAFLIGHT OSD can display this RSSI value in screen.
|
48CH 0/25/100/200mW VTX |
Brand Name: LDARC Channel: 40CH Power: 0/25/100/200mW Switchable Input Votlage: 2-4S Support IRC Tramp |
51mm 3-Blade Propeller |
Brand Name: LDARC Item Name: 51mm 3-Blade Propeller Color: Black Quantity: 10 CW & 10 CCW |
XT1102 9300KV Motor |
Brand Name: LDARC Model: XT1102 Item Name: 1103 9300KV Shaft Diameter: 1.5mm Input Voltage: 2-3S Motor Mounting Hole Size: 6.6 ( M1.4) Weight: 2.8g |
Runcam Nano 2 700TVL Camera |
Brand name: Runcam
Model: Nano 2
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155°
Signal System: NTSC / PAL
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: [email protected]
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Current : 110mA@5V [email protected]
Housing Material: ABS
Net Weight: 3.2g
Dimensions: L14mm*W14mm*H16mm
|
Lipo Battery ( All Version Have) | 3S 11.4V 300mAh 30C Lipo Battery |
Pacakge Included:
1x LDARC ET75- FPV Drone
1x Displaying Rack
1x Battery
4x ET75 Pillar
1x Tool
