Specification:
Brand Name: LDARC
Model: ET85D
Item Name: 87.6mm Wheelbase F4 4S 2 Inch FPV Racing Drone
Version: PNP ( without Receiver)
Drone Weight: 122g
ET85D 87.6mm Frame Kit | Wheelbase: 87.6mm Material: Carbon Fiber Upper Plate Thickness: 1mm Bottom Plate Thickness: 2mm Camera Angle: 15-45 Degree Kit Weight: 24g |
F411E12A F4 Flight Controller AIO 12A ESC | Brand Name: LDRAC Model: F411E12A Item Name: F4 Flight Controller MCU: STM32F411 MPU: MPU6000 Firmware Target: MATEKF411 OSD: AT7456E, Support Betaflight OSD Onboard Current Senstor ( Current Scale Value 210) Support DSM2/X, SBUS, IBUS, Crossfire, F.Port Receiver Input Voltage: 2-4S Lipo ESC Max Current 12A Each Way BLheli_S 4in1 ESC, Target: G_H_30 |
XT1105 4250 3-4S Brushless Motor | Brand Name: LDARC Model: XT1105 Item Name: 1105 4250KV Motor Input Voltage: 3-4S Lipo Shaft Diameter: 1.5mm Mounting Hole: 9x9mm, M2 Weight: 6.1g |
2045 2x4.5 2 Inch 4-Blade Propeller | Brand Name: LDARC Item Name: 2045 2x4.5 2 Inch 4-Blade Propeller Quantity: 10 CW & 10 CCW |
5.8G 48CH 25/100/200mW FPV Transmitter | Power: 0/25/100/200mW Working Voltage: 5V, Support IRC-Tramp Camera 5V Power Output CLC filter Antenna Use IPEX Socket |
FPV Camera ( NOT Included) | NO Camera, support 19mm / 20mm Width FPV Camera |
Receiver ( NOT Included) | NO Receiver |
Lipo Battery ( NOT Included) | Recommend LDARC 4S 14.8V 430mAh Lipo Battery XT30 Plug |
Features:
- 4S HD Digital Whoop
- Compatible with Caddx Vista Module
- Light Weight, less than 250g
Package Included:
1x ET85D FPV Drone ( NOT Include DJI Air Unit, Receiver, Camera)
10x 2045 4-Blade Propeller CW
10x 2045 4-Blade Propeller CCW
6x Rack 2x Sticker
4x 1.2*4 Screw
4x 1.4*10 Screw
