Description:
Brand Name: ImmersionRC
Item Name: 5.8G 600mW AV Transmitter
Connector: SMA, with supplied 5.8GHz antenna
Input voltage range: 6 - 25v
Camera Power Supply: 1000mA / 5v
Video Input: 1Vpp, 75 Ohms
Size: 120 x 60 x 20mm
Weight: 20 grams
Features:
600mW (28dBm, + / - 1dB) of clean output power
Frequencies: 5740, 5760, 5780, 5800, 5820, 5840, 5860MHz
Not affected by 2.4GHz RC radios
On-board quiet switching regulator, powers 5v cameras (including HD versions)
Brand Name: ImmersionRC
Item Name: 5.8G 600mW AV Transmitter
Connector: SMA, with supplied 5.8GHz antenna
Input voltage range: 6 - 25v
Camera Power Supply: 1000mA / 5v
Video Input: 1Vpp, 75 Ohms
Size: 120 x 60 x 20mm
Weight: 20 grams
Features:
600mW (28dBm, + / - 1dB) of clean output power
Frequencies: 5740, 5760, 5780, 5800, 5820, 5840, 5860MHz
Not affected by 2.4GHz RC radios
On-board quiet switching regulator, powers 5v cameras (including HD versions)
Specification
General |
FPV Equipments: Transmitter |
---|---|
Dimension and Weight |
Product weight: 0.020 kg
Package weight: 0.050 kg Package size (L x W x H): 12.00 x 6.00 x 2.00 cm / 4.72 x 2.36 x 0.79 inches |
Package Contents |
Package Contents: 1 x Transmitter, 1 x Antenna ( SMA Connector ), 1 x DC Power Cable |
