Omnibus F7 Pro Flight Controller Built-in Dual Gyro AIO OSD Current Sensor and LC Power Filter
Specification: ( Manual)
Item Name: Omnibus F7 Pro Flight Controller
Processor: STM32 F745 MCU ( Faster than the current F3 and F4 processors)
Size: 36x36mm
Mount Hole: 30.5x30.5mm
Mount Hole: 30.5x30.5mm
Weight: 6.6g
Two gyros on the flight controller: a MPU6000 for sampling up to 8khz ;and ICM20608 for sampling up to 32khz
- Built-in betaflight OSD
- Built-in Current Sensor
- Built-in 5V LC-power filter
- Built-in Barometer
- Support DShot ESC
- Support DShot ESC
- SD card reader for recording black box data (SD card not included)
Supports 2-4s natively, 5-6s with 220uf 35V capacitor
5v/1A regulator
Support PPM/SBUS/IBUS/DSM2/DSMX protocol receiver
LED_strip ready pin headers
Buzzer ready pin headers
Smart port ready Pin headers
Compatible 4 in 1 ESC with JST-SH 1.0 6pin housing
Package Included:
1xOmnibus F7 Pro flight controller
Package Included:
1xOmnibus F7 Pro flight controller
4x M3 screws
5x M3+4x 5 Nylon column
4x M3 Nut
