Specification:
Brand name: Flyduino
Item name: KISS Race Edition 24A Brushless ESC
Input Voltage: 2~5S (7.4~18.5V)
Con.Current:24A
Peak Current(10s):35A
Con.Current:24A
Peak Current(10s):35A
Dimensions: 19 x 27mm
Weight: 3.6g
Features:
• 32-bit ARM Cortex MCU@48Mhz
• Telemetry capable (voltage, current, temperature, RPM)
• Overcurrent protection (measures the current and reduces it to a max of 30A)
• Over temperature protection (reduces max power if temp exceeds 120°C)
• Expanded adaptive auto timing
• Specifically designed for racing drones (24 amps continuous even with bad cooling)
• High max RPM (64000 with a 14 pole motor)
• Accurate RPM control (950 step resolution)
• Very fast throttle response
• Linear throttle response
• Active freewheeling
• Regenerative braking
• No external electrolytic capacitor required
• Fast FET switching due to the use of gate drivers
Oneshot42, Oneshot125 and normal (25 – 500Hz) PWM auto detected.
Direct Memory Access
Guarantees a low CPU load using protocols like DSHOT 600/1200
Hardware is prepared for using the newest digital protocols
Operating voltage 6 – 25V
500,000 ERPM maximum field speed (use of 450,000 recommended)
Package Included:
1 x KISS Race Edition 24A Brushless ESC
