Pixhack 2.8.4pro 32bit Autopilot Improved Version Flight Control

Main Features:
● Independent IMU inertial control unit, built-in suspension damping mechanism, can effectively inhibit the rack vibration
● Based on Pixhawk powerful open source programs and a wealth of external extensions
● Peripheral interfaces such as GPS /Telem / Power and common APM2.5 / 2.6 / 2.8
● Advanced 32-bit ARM Cortex M4 high-performance processor
● 8 PWM / servo output, maximum support 8-axis multi-rotor
● Provide automatic and manual mode
● Provides redundant power input and failover capabilities
● Multi-color LED lights
● Multi-tone buzzer interface
● Micro SD records flight data

Hardware Parameters:
Processor
- 32-bit 2Mb cache STM32F427 Cortex M4 with hardware floating point processing unit
- Frequency: 168MHz, 256K RAM
- 32 bit STM32F103 backup coprocessor

Sensor
- L3GD20 3-axis digital 16-bit gyroscope
- LSM303D 3-axis 14-bit acceleration / magnetometer
- MPU6000 6-axis accelerometer / magnetometer
- MS5611 high-precision barometer

Interface
- Futaba SBUS compatible input
- PPM signal input
- PWM signal output
- I2C interface 1 ( 1.25mm pitch 4pin JST socket )
- Telemetry interface 2 ( 1.25mm pitch 5pin JST jack )
- Power module interface 1 ( 1.25mm pitch 6pin JST jack )
- GPS interface 1 ( 1.25mm pitch 5pin JST jack )
