PUDA Vert Racer 5" 230mm FPV Racing Frame 5mm 10mm Arm Double Layer Arm Carbon Fiber RC Drone
At 10mm tall and 4.5mm wide, the arms allow for the motor mount to be cut from the layer, with the bottom layer adding extremely rigid support and the benefit of aerodynamic positioning. The arms then double as standoffs, with the kit only needing a total of two for camera mounting.
Mid-mount battery positioning helps gives the frame fluid maneuverability, while a double strap plate and adequate prop berth can house up to a 1600 (Who Cares:) lipo safely.
Description:
Brand name: PUDA
Item name: Vert Racer 5" 230mm FPV Racing Frame
Frame weight: 93g approx
Motor to motor: 230mm
Frame shape: FPV Racing
Arm thickness: 5mm + 5mm (double layer)
Top plate thickness: 2mm
Motor mount pattern: 22xx
Max stack height: 15mm
Recommended parts (not included):
Brushless motor: 2205-2206 / 2300-2700kv
ESCs: 30a
Prop size: 5"
LiPo: 3S-4S / 1300-1500mah
Package included:
1 x PUDA Vert Racer 5" 230mm FPV Racing Frame
