QX-Motor 30mm 6 Blades EDF Unit With QF1611 7000KV Brushless Motor
Description:
Brand Name: QX-Motor
Item Name: EDF unit with brushless motor set
EDF Unit: 30mm 6 blades
Brushless Motor: QF1611-7000KV
Specifications of Motor:
KV 7000 Idle Current @10.0V 0.5A Configuration 9N6P No.of Cells(Lipo) 2S Stator Diameter 13mm Max Continuons Current(A)/60s 12A Stator Length 11mm Max Continuous Power(W)/60s 120W Motor Dimension 16x25mm Weight 19.5g
Testing Data:
Prop Volts(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) Throttle 30FAN 11.1 1.7 18.87 44 1.55 2.33 0.08 50% 30FAN 11.1 2.5 27.75 57 2.01 2.05 0.07 60% 30FAN 11.1 3.3 36.63 74 2.61 2.02 0.07 70% 30FAN 11.1 4.8 53.28 104 3.67 1.95 0.07 80% 30FAN 11.1 11.2 124.32 220 7.76 1.77 0.06 100%
Package Included:
1x QX-Motor 30MM 6 Blades EDF Unit With QF1611-7000KV Brushless Motor
