RacerCube Integrated F3 EVO Flight Controller 4 In 1 20A F396 ESC Frsky 8CH PPM/SBUS Receiver for X Racing Frame
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/ead6e3eb-93a1-1443-7702-2e6ba8176433.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/28e59f02-db1e-a32e-713d-8f790465d379.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/93a66d26-9475-4e3f-62b4-b21320b8171b.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/8a241e7b-78a6-515b-673f-ba0933431c74.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/074cc343-4dd9-b01f-abd5-c302c3fa6d74.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/849fdd8a-59b1-5c6c-c511-ca0683dc3fc8.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/61149651-792f-15ee-e426-62eea281ff67.png)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/73b31f81-ce7c-51a4-4a30-cd3761aacd16.png)
![](http://img.banggood.com/images/oaupload/banggood/images/9F/03/67793a2f-0803-47dc-01f2-35385773933d.png)
to look at the manual: http://img.banggood.com/file/products/20161121024948RacerCube manual.doc
Specification:
Weight: 23 g
Size: 36mm * 36mm * 25mm
Installation hole distance: 30.5mm * 30.5mm
Name Specification F3 EVO Flight Control Integrated MWOSD and PCB board
Suitable for 120-330 wheelbase multirotor frame kit, especially for X and Monster DIY frame kitName Specification F3 EVO Flight Control Integrated MWOSD and PCB board
Firmware: Cleanflight 1.13.0
Target: SP RACING F3 EVO
STM32F303 CPU, 72Mhz inc FPU
MPU9250 accelerometer/gyro/compass (connected via SPI)
BMP280 barometer
Compatible PPM/CPPM/SBUS/DSM2/DSMX Receiver
Integrate PDB support 2s-6s Input
Frsky Receiver
Integrated F3 Flight Control BLACKBOX Functionality and External Expansion Interface
Channel: 8
Working voltage: 4-6.5V
Frequency range: 2400-2483.5Mhz
Output signal: SBUS/PPM
Dual way transmission: Yes(D8 mode)
Transmit distance: > 1Km
Feedback signal: RSSI, 3S voltage (A1)
With Failsafe @Throttle 3ch
Compatible with X9D(D8 mode)/XJT (D8 mode)/DJI/DFT/DHT
Racercube LittleBee ESC
4IN1 20A*4
F396 MCU, 48Mhz Runs BLHELI LittieBee Pro 20A firmware
Support 3-6S Li-po
4PWM input,
Supports oneshot PWM
Only 35x35mm, mount holes 30x30mm (on new batch, the holes will bechanged to 30.5x30.5mm)
Supports damped light
no BEC output
Features:
1. Buzzer ready
2. RSSI/ VOLTAGE DETECOTR Ready
1. Buzzer ready
2. RSSI/ VOLTAGE DETECOTR Ready
3. Ultra-light integration suite,PNP, do not need cumbersome wiring
4. F3_EVO FLIGHT CONTROLLER Jaw-Dropping Flight Performance
4. F3_EVO FLIGHT CONTROLLER Jaw-Dropping Flight Performance
5. STM32F3 chip F3 EVO flight control, support CLEANFLIGHT / BETAFLIGHT program
6. Built-in MWOSD, aircraft real-time data status real-time back to the FPV display or GOGGLES
7. Built-in SD card, integrated CLEANFLIGHT BLACKBOX function, PID adjustment more at a glance
6. Built-in MWOSD, aircraft real-time data status real-time back to the FPV display or GOGGLES
7. Built-in SD card, integrated CLEANFLIGHT BLACKBOX function, PID adjustment more at a glance
8. Integrated FRSKY compatible 8-channel SBUS / PPM two-way receiver, FRSKY Taranis X9D and DJT / DFT / XJT tuner directly on the frequency can be used
9. 4IN1 ESC Little BEE 20A F396 Chip ESC Ready, BLHELI Pass-through Ready.
Based on high-quality F396 MCU ESC, support Oneshot125 / Multishot, support Damped Light function, can be directly configured by CLEANFLIGHT
Based on high-quality F396 MCU ESC, support Oneshot125 / Multishot, support Damped Light function, can be directly configured by CLEANFLIGHT
Package included:
1 x F3 EVO Flight Control
1 x Frsky Receiver
1 x Racercube 4IN1 LittleBee ESC
