Realacc Horns 100 Micro 3D FPV Racing Drone BNF Dual 600TVL Cameras 5.8G 25MW 48CH VTX F3 OSD Dshot600
Description:
Brand name: Realacc
Item name: Realacc Horns 100 Micro 3D FPV Racing Drone BNF
Size: 120mm*120mm*60mm
Weight: 75g (battery not include)
Flight controller: Minicube Betaflight F3 Flight controller built-in OSD
Motor: Realacc 1104 KV7500 brushless motor
Propeller: 50mm 5-blades propeller
Camera: 600TVL HD CMOS 1/4inch * 2
VTX: 5.8g 25MW 48CH NTSC/PAL Video transmitter * 2
Battery: 2S 7.4V 450mah 80C lipo battery
Flight time: 3 minutes
Buzzer Ready
Require: SKY02S 3D FPV Goggles
Receiver option:
Compatible Frsky D8 mode SBUS receiver (RSSI ready)
Original Frsky D16 mode SBUS receiver (Smart port ready)
Compatible Flysky 8ch AFHDS2A receiver Ibus output with Failsafe
Compatible Specktrum DSM2/DSMX receiver
Minicube Betaflight F3 6DOF Flight controller built-in OSD 2-3S:
Size: 27mm*27mm*5mm
Mount hole: 20mm*20mm
Processor: STM32 F303 MCU
Sensor: SPI Sensor MPU6000
Built-in Betaflight OSD (Batt voltage, RSSI, Artificial Horizon, Fly mode, Flytime, Craft name etz.)
Firmware version: Betaflight 3.1 Dshot600 ready
Target: OmnibusF3
OSD: Betaflight OSD
Work voltage: 2S-3S lipo battery
Minicube 4 in 1 10A ESC BLHELI_S 16.5 2-3S:
Size: 27mm*27mm*5mm
Mount hole: 20mm*20mm
Firmware version: BLHELI_S 16.5
BB2, 48MHZ Chip
Lipo Battery: 2S-3S
Con. Current: 10A
Peak Current: 15A (10S)
BEC: 5V @0.1A
Programming: YES
Betaflight pass-trough ready
Dshot600 ready (Default)
Support oneshot42 oneshot125 Multishot Dshot
Damped light on
Features:
Extremely light and more powerful.
Dual cameras & video transmitters.
3D FPV flight, amazing experience.
STM32 F303MCU + BLHELI_S ESC make your operating feel more stability and silky.
Adjustable angle of camera.
Jaw-dropping flight performance.
Betaflight support.
Acro mode / Air mode /Angle mode support.
Built-in OSD (Using F3 MCU controls OSD over SPI bus in DMA mode).
OSD configuration has been include in BETAFLIGHT GUI.
Radio Stick to control PID Tunes.
BLEHELI_S pass-through ready.
Telemetry RSSI Output ready (Compatible Frsky D8 Version).
Smart port ready (Original Frsky D16 Version).
Manuals:
Compatible DSM2 DSMX BNF version manual
Compatible Frsky D8 BNF version manual
Frsky D16 BNF version manual
Compatible Flysky BNF version manual
Package included:
1 x Realacc Horns 100 Frame kit
1 x Minicube Betaflight F3 6DOF flight controller build-in OSD
1 x Original Frsky D16 receiver / Compatible Frsky D8 / DSM / Flysky AFHDS2A Receiver (optional)
4 x Realacc 1104 7500KV brushless motor
1 x Minicube 10A BLHELI_S 16.5 2-3S 4 in 1 ESC Dshot600
4 x 50mm 5-blades propeller CW
4 x 50mm 5-blades propeller CCW
2 x 600TVL HD CMOS 1/4 inch camera
2 x 5.8g 25MW 48CH NTSC/PAL VTX
1 x 2S 7.4V 450mah 80C lipo battery JST plug
1 x Buzzer (integrated in receiver)
